4.5 Anti-jamming system

The anti-jamming system, available as an accessory (see
paper output while printing is still in progress. This system is composed of an infrared relex sensor that detects the lifting
of the paper. The user that blocks the paper bezel before the printing end, causes the lifting of the paper inside the device.
This movement disengages the relex sensor: printing is interrupted until the paper bezel is not unblocked.
1
2
During the printing of the ticket, the obstruction of the paper bezel causes lifting of the paper inside the device.
NOTE: Use paper with a weight between 58 g/m
30
The device starts the ticket printing.
The sensor is engaged generating the status of 'paper jam'.
2 and 74 g/m
chapter 10), starts operating when the user tries to block the
not engaged
Sensor
engaged
2 .
Sensor
