  • Page 1 USER MANUAL TPTCM112II DOMC-0001e Commands manual:...
  • Page 2 All rights reserved. Total or partial reproduction of this manual in whatever form, whether by printed or elec- tronic means, is forbidden. While guaranteeing that the information contained in it has been carefully checked, CUSTOM ENGINEERING SPA and other entities utilized in the realization of this manual bear no responsibility for how the manual is used.
  • Page 3 THE IMAGES USED IN THIS MANUAL ARE USED AS AN ILLUSTRATIVE EXAMPLES. THEY COULDN’T REPRODUCE THE DESCRIBED MODEL FAITHFULLY. UNLESS OTHERWISE SPECIFIED, THE INFORMATION GIVEN IN THIS MANUAL ARE REFERRED TO ALL MODELS IN PRODUCTION AT THE ISSUE DATE OF THIS DOCUMENT. TPTCM112II User Manual...
  • Page 4 TPTCM112II User Manual...

  • Page 5: Printer Components

    PRINTER COMPONENTS TPTCM112II-UC-0051 Unblocking lever for print head Near paper end sensor Paper in sensor Paper roll holder LF LINE FEED key Plastic seeger to adjust the paper width FF FORM FEED key Autocutter POWER ON Led Paper out STATUS Led Printing mechanism + head sensor NEAR PAPER END Led Printing mechanism motor...
  • Page 6 6 TPTCM112II User Manual...

  • Page 7: Table Of Contents

    TABLE OF CONTENTS TABLE OF CONTENTS 1 INTRODUCTION ..............................9 1.1 Explanatory notes used in this manual ......................9 1.2 General safety information ..........................9 1.3 Unpacking the printer ............................. 10 1.4 Printer description ............................11 2 INSTALLATION AND USE ............................. 13 2.1 Power Supply ..............................
  • Page 8 TABLE OF CONTENTS 8 TPTCM112II User Manual...

  • Page 9: Introduction

    1. INTRODUCTION 1 INTRODUCTION In addition to the Introduction which includes a description of the explanatory notes used in the manual, general safety information, how to unpack the printer and a brief description of the printer including its basic features, this manual is organized as follows: Chapter 1: Contains the information required for correct printer installation and its proper use...

  • Page 10: Unpacking The Printer

    1. INTRODUCTION 1.3 Unpacking the printer Remove the printer from its carton being careful not to damage the packing material so that it may be re-used if the printer is to be transported in the future. Make sure that all the components illustrated below are present and that there are no signs of damage.

  • Page 11: Printer Description

    1. INTRODUCTION 1.4 Printer description The TPTCM112II printer is comprised of a metal frame, paper roll holder, printing mechanism and a cutter. The following keys are located on the control panel: FF FORM FEED, LF LINE FEED, “POWER ON” Led, “NEAR PAPER END”...
  • Page 12 1. INTRODUCTION 12 TPTCM112II User Manual...

  • Page 13: Installation And Use

    2. INSTALLATION AND USE 2 INSTALLATION AND USE 2.1 Power Supply For the power supply, the printer is equipped with a male, 90° mobile screw terminal. The signals on the power sup- ply connector pins are as follows: SIGNAL DESCRIPTION Ground signal +Vin* Vcc Power supply...

  • Page 14: Self-Test

    2. INSTALLATION AND USE 2.2 Self-test Printer operating status is indicated in the confi guration print-out in which, next to the name of the components dis- played (see Figure), the following information is given: • under INTERFACE is given the interface present.

  • Page 15: Confi Guration

    2. INSTALLATION AND USE 2.3 Confi guration During power-up, if both the LF LINE FEED and FF FORM FEED keys are held down, the printer enters confi gura- tion mode and prints-out the SETUP report. It will remain in standby until a key is pressed or characters are received through the communication port (see Hexadecimal dump).

  • Page 16: Hexadecimal Dump

    2. INSTALLATION AND USE 2.4 Hexadecimal dump HEXADECIMAL DUMP This function is used to diagnose the characters received through the communication port; for every 8 characters received, the hexadecimal and corresponding ASCII codes 12345678 31 32 33 34 35 36 37 38 are printed out.

  • Page 17: Maintenance

    2. INSTALLATION AND USE 2.5 Maintenance WARNING Make sure no water or other liquids seep inside the printer. BEWARE Before any type of work is done on the machine, disconnect the power supply cord from the mains outlet. ATTENTION Do not touch the head heating line with bare hands or metal objects. Do not perform any operation inside the printer immediately after printing because the head and motor tend to become very hot.

  • Page 18: Cleaning The Print Head: Tptcm112Ii-Uc-0051

    2. INSTALLATION AND USE 2.5.2 Cleaning the print head: TPTCM112II-UC-0051 To open the printer proceed as follow: Turn down the autocutter unit to the maximum opening position. Unblock the printing mechanism as shown (see Figure). Clean the printing head heating line using a nonabrasive cloth moistened with isopropyl alcohol. ATTENTION! DO NOT TOUCH THE HEAD HEATING LINE WITH BARE HANDS OR METAL OBJECTS.

  • Page 19: Cleaning The Autocutter: Tptcm112Ii-Uc-0051

    2. INSTALLATION AND USE 2.5.3 Cleaning the autocutter: TPTCM112II-UC-0051 To clean the autocutter, proceed as follows: Insert a fl at-head screwdriver into the opening paper output and place the thumb on the bottom edge to protect the autocutter unit from scratches (see fi gure). Lever with the screwdriver to release the lid. Slightly turn down the autocutter unit.
  • Page 20 2. INSTALLATION AND USE LABEL REMOVER 20 TPTCM112II User Manual...
  • Page 21 2. INSTALLATION AND USE printer Command: $1B $69 TPTCM112II 21 User Manual...
  • Page 22 2. INSTALLATION AND USE LABEL REMOVER 22 TPTCM112II User Manual...

  • Page 23: Loading The Paper: Tptcm112Ii-Uc-0051

    2. INSTALLATION AND USE 2.5.4 Loading the paper: TPTCM112II-UC-0051 To load the paper on the printer proceed as follow: Push the adjustable fl ange in the direction indicated in the fi gure and insert the plastic seeger in the appropriate location according to the paper width (80, 100 or 112mm).

  • Page 24: Changing The Paper Roll: Tptcm112Ii-Uc-0051

    2. INSTALLATION AND USE 2.5.5 Changing the paper roll: TPTCM112II-UC-0051 ‘PAPER AUTOLOAD’ ENABLED: Position the paper roll, so that it unrolls correctly as shown (see Figure). Before inserting the paper, make sure the cut is straight. Insert the paper into the infeed slot and wait for the roll to be loaded automatically and cut. Remove the exceeding paper.

  • Page 25: Ff Form Feed Key

    2. INSTALLATION AND USE ‘PAPER AUTOLOAD’ DISABLED: Position the paper roll, so that it unrolls correctly as shown (see Figure) and lift the print head by using the un- blocking lever for print head (see Figure). Insert the paper into the infeed slot and have it pass beyond the print head and the cutter (see Figure). Lower the lever.
  • Page 26 2. INSTALLATION AND USE FF LF ® TPTCM60 printer 26 TPTCM112II User Manual...

  • Page 27: Interface

    3. INTERFACE 3 INTERFACE 3.1 RS232 serial interface The printer has an RS232 serial interface and is connected by means of a 9 pin female connector (see Figure). In the following table, the signals present on the connector are listed: RS232 SIGNAL IN / OUT...
  • Page 28 3. INTERFACE The following diagrams show examples of connections between the printer and the Personal Computer using a 9 pin female connector. Printer ATTENTION Using a serial cable it’s better to install a ferrite at the end of the same cable. 28 TPTCM112II User Manual...

  • Page 29: Usb Interface

    3. INTERFACE 3.2 USB Interface The printer with USB interface complies to USB 1.1 specifi cations with the following specifi cations: • Communication speed equal to 12 Mbit/sec. • Type of connector “Receptacle series B”. Refer to the table below for the connector pin signals: USB type B SIGNAL DESCRIPTION...
  • Page 30 3. INTERFACE 30 TPTCM112II User Manual...

  • Page 31: Technical Specifications

    4. TECHNICAL SPECIFICATIONS 4 TECHNICAL SPECIFICATIONS Table below gives the main technical specifi cations for the printer. GENERAL Serial RS232 Available interfaces (serial RS232) from 1200 to 57600 bps Communication speed (USB) 1.1 Near paper end, paper in presence, label gap, head up, head temperature Sensors OPTIONAL: Near paper end (on paper roll holder support) Printing driver...
  • Page 32 4. TECHNICAL SPECIFICATIONS Core type Cardboard or plastic Internal roll core diameter Ø50 ± 1 mm Paper end Not attached to roll core ELECTRICAL SPECIFICATIONS Power Supply 24 Vdc ± 10% Absorptions Stand by 0.07 A Average 1.3 A ENVIRONMENTAL CONDITIONS Operating temperature 0-50°C Relative humidity...

  • Page 33: Character Specifi Cations

    4. TECHNICAL SPECIFICATIONS 4.1 Character Specifi cations ESC/POS™ EMULATION Number of columns PRINTING SPEED Lines / sec 16.7 16.7 16.7 Characters / sec 1336 1736 CHARACTER (W x H mm) Normal 1.7 x 3 1.2 x 3 1 x 3 Double height 3.4 x 3 2.4 x 3...

  • Page 34: Label Dimension: Tptcm112Ii-Uc-0051

    4. TECHNICAL SPECIFICATIONS 4.2 Label dimension: TPTCM112II-UC-0051 To use correctly the alignment command it is necessary to use labels with the following dimensions (see fi gure): A ≥ 4 mm B = 80, 100, 112 mm NOTE: It is not guaranteed the fall of the ticket. 34 TPTCM112II User Manual...

  • Page 35: Printer Dimensions: Tptcm112Ii-Uc-0051

    4. TECHNICAL SPECIFICATIONS 4.3 Printer dimensions: TPTCM112II-UC-0051 N°3 FILETTI Ø4 114 ±0.1 222.2 90.2 TPTCM112II 35 User Manual...

  • Page 36: Printer Dimensions With Paper Roll Holder Support: Tptcm112Ii-Uc-0051

    4. TECHNICAL SPECIFICATIONS 4.4 Printer dimensions with paper roll holder support: TPTCM112II-UC-0051 285,25 155,5 36 TPTCM112II User Manual...

  • Page 37: Character Sets

    5. CHARACTER SETS 5 CHARACTER SETS The printer has six font of 224 characters. See the following example: ESC/POS 58 Colomns ESC/POS 80 Colomns ESC/POS 104 Colomns TPT 34 Colomns TPT 52 Colomns TPT 104 Colomns TPTCM112II 37 User Manual...
  • Page 38 5. CHARACTER SETS If it has the version with Chinese simplifi ed font GB2312 at the end of the FONT TEST is printed all characters set as shown. 38 TPTCM112II User Manual...
  • Page 39 5. CHARACTER SETS With this version must be send two bytes to addressing characters: the fi rst byte identifi es the table, the second byte identifi es the row and column in the table. In fi gure is reported an example of characters mapping; the x symbol identifi...
  • Page 40 5. CHARACTER SETS 40 TPTCM112II User Manual...

  • Page 41: Accessories

    APPENDIX A - ACCESSORIES AND SPARE PARTS A.1 ACCESSORIES A.1.1 Power supply Switching power supply 24V 150W PPSPS-S150-24 193.0 4 - M3 - P 0.5 61.5 13.5 3.4 HOLE 3 - M3 - P 0.5 INPUT SPECIFICATIONS Input voltage 88 ÷ 132 Vac / 115V or 176 ÷ 264 Vac / 230V (selected by switch) Current 0 ÷...

  • Page 42: Connection Cables

    APPENDIX A - ACCESSORIES AND SPARE PARTS A.1.2 Connection cables WRDATI-USB-MM-AB-1.8-3 USB cable A to B - 1,8 mt WRDATI-RS232-9-9-18-3 Male to female serial cable DB-9 - 1,8 mt A.1.3 Adjustable paper roll holder support PCXSP-TPTCM112 Paper roll holder support kit + NPE for 180mm paper roll + fi...
  • Page 43 APPENDIX A - ACCESSORIES AND SPARE PARTS TPTCM112II 43 User Manual...
  • Page 44 APPENDIX A - ACCESSORIES AND SPARE PARTS 44 TPTCM112II User Manual...
  • Page 45 APPENDIX A - ACCESSORIES AND SPARE PARTS TPTCM112II 45 User Manual...

  • Page 46: Spare Parts

    APPENDIX A - ACCESSORIES AND SPARE PARTS A.2 SPARE PARTS RCT111,5x120E-50MM-90GR Thermal paper roll 111,5mm 90gr (d=120 core 50mm) 46 TPTCM112II User Manual...
  • Page 48 CUSTOM ENGINEERING SPA World Headquarters Via Berettine, 2 - 43010 Fontevivo, Parma ITALY Tel. +39 0521 680111 - Fax +39 0521 610701 info@custom.biz - www.custom.biz All rights reserved www.custom.biz...
