5 CONFIGURATION

5.1 Coniguration by keys

To enter the coniguration mode and print a setup report with the operating parameters of the device, proceed as follows.
1
Connect the serial
Connect the serial cable
cable (see
(see paragraph 3.2).
2
While pressing the LF LINE FEED key, While pressing the LF LINE FEED key,
switch on the device by inserting the power supply switch on the device by inserting the power supply
cable (see paragraph 4.3). cable (see
paragraph 3.2).
+VCC
paragraph 4.3).
3
PRINTER SETUP
The device prints the report with the
settings parameters. Follow the instruction printed on
the paper to proceed with configuration procedure.
31
