Installing a WX
Switch
C WX S
ONNECTING A WITCH
Table 9 lists the mounting hardware and tools required for each type of
installation.
Table 9 Required Mounting Hardware and Tools
Mounting Option
Equipment rack
Front-mount or
center-mount option for
the WX4400 switch
Front-mount option for
the WX1200 switch
Tabletop
WARNING: To reduce the risk of equipment damage, make sure the WX
switch is installed so that the mechanical load on the device is evenly
distributed. For example, make sure the switch is level in the equipment
rack, is evenly fastened by screws on either side, and does not have a
heavy object resting on one side of the switch.
You can mount a WX switch in a standard 48.26-cm (19-inch) equipment
rack or on a tabletop. Each WX switch is shipped with two brackets for
rack mounting and four adhesive rubber feet for tabletop mounting. The
WX4400 mounting brackets support either front or center mounting. The
WX1200 mounting brackets support front mounting only.
To install a WX switch, use one of the following procedures.
WARNING: Earth grounding is required for a WX switch installed in a
rack. If you are relying on the rack to provide ground, the rack itself must
be grounded with a ground strap to the earth ground. Metal screws
attaching the switch to the rack provide ground attachment to the rack.
WARNING: In the U.S., overcurrent protection must be provided by the
installation. Branch circuit protection in accordance with National Fire
Required Hardware and Tools
Mounting brackets
Four rack-mount screws and
screwdriver
Note: Equipment racks vary, and
the screw and screwdriver type
depend on the equipment rack.
Power cords
Serial console cable
Four adhesive rubber feet
Power cord(s)
Serial console cable
Included with
the Product
Yes
No
Yes (one)
Yes
Yes
Yes
Yes
