22 C 2: I
HAPTER NSTALLING AND
C WX S
ONNECTING A WITCH
Table 5 Serial Console Pin Signals
WX Pin Usage
2 Receive
3 Transmit
5 Ground

Network Cables

Table 6 lists the interface types supported by WX switches and the cable
type required for each type of interface.
Table 6 Ethernet Interfaces
Link Type Cable Type
10/100BASE-T Cat 5 copper
Straight-through or crossover
signaling
1000BASE-SX Multimode 50-µm fiber
Multimode 62.5-µm fiber
1000BASE-LX Single mode 9/10-µm fiber
Multimode 50-µm fiber
Multimode 62.5-µm fiber
1000BASE-TX Cat 5 copper
Can use straight-through or
crossover signaling, provided all four
wire pairs are connected
The WX1200 supports 10/100 Ethernet connections. Table 7 lists the link
type and properties of the supported connections.
PC Pin Usage
3 Transmit
2 Receive
5 Ground
Connector
Type
RJ-45
SC
SC
SC
SC
SC
RJ-45
Maximum
Distance
100 m
(328 feet)
550 m
(1804.5 feet)
275 m
(902.2 feet)
10,000 m
(32,808.4 fe
et)
550 m
(1804.5 feet)
550 m
(1804.5 feet)
100 m
(328 feet)
