P
RODUCT OVERVIEW
FRONT
❶
❷
❸
❶ BNC antenna connector
❷ REC button
(for audio recording on SD card)
❸ Play audio from SD card
❹ Led ON
(green when transmitter is on)
❺ SYNC button (for automatic
synchronization with Wisycom RX)
❻ FN button
(for quick menu selection)
❼ ON AIR led
(green when transmission is active)
DISPLAY
This is the first menu displayed after power up.
Status of Transmission
Group & Channel
Frequency
❹ ❺
❻ ❼
❿ ⓫
⓬ ⓭
❽
❾
❿
⓫
⓬
⓭
RPU500-Tx User Manual
TALK button
(to activate TALK transmission)
VOLUME knob
SAVE or SEL button
EXIT button
DOWN arrow button
UP arrow button
Name of transmitter
Level of RF Power
Compander
Modulation Bandwidth (Wide/Narrow)
Level of Battery (% and minutes)
Level of audio input
Time
❽
❾
