PRODUCT OVERVIEW

1. OLED white display (128x64 px)
2. 4 setup buttons
3. battery compartment latch
4. MIC connector (LEMO 3pin)
5. Antenna connector (LEMO 1pin)
6. LED1 for audio
7. LED2 for RF and battery
2
4
1
2
3
11
MTP60 multi-band bodypack transmitter
6 8 7
SEL
MENU
ON GAIN
REC
EXIT CH
OFF
8. IrDa (infared) interface
9. LED3 for recording
10. LED4 for battery recharging
11. battery compartment
12. Micro-SD card slot
13. USB-C connector (power and control)
13
5
9
10
12
