No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
2.2.2 Spindle control output/ Universal output interface 1
We define the interface from left are: GND1(Output GND),VSO(0-10V adjustable speed
output),OT1,OT2,OT3,OT4.
Take Nowforeuer inverter as the example. Spindle control output and the inverter connection
showed as Figure 2-7.If ACM and DCM are closed,only need to connect one port.
Manual of NVCM
Mark
XT5
XT7
GND
XT10
XT12
XT13
XT15
GND
XT6
XT8
XT9
XT11
GND
XT14
XT16
☞Output in mach3 should be configured to PORT 2
Table 2-2. Definition of Output
- 10 -
Definition
Output5
Output7
Ground and common end
Output10
Output12
Output13
Output15
Ground and common end
Output6
Output8
Output9
Output11
Ground and common end
Output14
Output16
