  • Page 1 百年品质，值得信赖 —— 您的产品名称 MACH3 LPT port USB Card NC200 Manual...

  • Page 2: Table Of Contents

    2.1 Product connection define and method ....................- 5 -  Chapter 3.  Software Installation ........................- 10 -  3.1 MACH3 Install ............................ - 10 -  3.2 NC200 Plug-in installation ........................- 13 -  Chapter 4.  Setting of software ........................- 14 -  4.1 Open software ............................- 14 - ...

  • Page 3: Chapter 1. Introduction

    Introduction 1.1 Product Introduction Novusun CNC has engaged in the Numerical control industry for 7 years, specialized in the research, development and production of various CNC controller systems with high quality and high reliability. We produce the Brushless DC motor, Stepper motor driver, and also 1 to 6 aixs CNC motion controllers.。...

  • Page 4: Products Appearance And Size

    Compatible with MPG input, support the digital display MPG from our company。 1.3 Products Appearance and size NC200 motion controller is with the plastic shell structure. The controller appearance as the Figure 1-1 show: The products overall size is 56.8mm*54.1mm*22mm ；...

  • Page 5: Substantival Explanation

    Manual of NC200 1.4 substantival explanation When operate the NC200,where will be a lot of English abbreviation,now we list all of them for your kindly references: FRO:Feedingadjust:During the operating process,the F value already set,and need to adjust the current feeding speed, then we can adjust FRO value to realize it.

  • Page 6: Noting And Waring

    Manual of NC200 1.5 Noting and Waring Free from exposure to the electronics without waterproof function.Please environment as dry as possible. This is the icon. Wiring warning, the IO input terminal of this equipment support the equipment with source switch (such as Inductive proximity switch.)When using such kind of switch, attention please: avoid the +terminal and –terminal of...

  • Page 7: Chapter 2. Connection

    Manual of NC200 Chapter 2. Connection 2.1 Product connection define and method Figure2-1. Product wiring section and interface summary As the Figure 2-1 showed,the connection of the controller includes USB connection interface, MPG interface and LPT controller port. Now we descript them in details as below.
  • Page 8 Manual of NC200 stepper motor control port. and PIN10-PIN13,PIN15 are input PINs, which can be set as probe, limit, estop and home. See as table 2-1. Figure2-2. sequence of LPT port INPUT & OUTPUT Note OUTPUT PORT Can be set as usual output\stepper...
  • Page 9 OUTPUT PORT PWM output 18-25 Ground Table 2-1. Stepper driver control interface define NC200 can replace computer's LPT port, and performs better than computer's LPT port. This port connect to stepper driver board see as figure 2-3. - 7 -...
  • Page 10 Manual of NC200 Figure2-3. Connect with Stepper driver board 2.2.2 MPG connection As shown in Figure 2-2 marked 2 of the location of the serial port MPG, the port type is RJ45, that is, the common standard network interface. Serial pulse generator pulse generator is the standard pulse generator, the axis of choice, such as the choice of power through the serial port and host interaction.
  • Page 11 A+ of MPG FHA- A- of MPG FHB+ B+ of MPG FHB- B- of MPG 2.2.3 USB Port As the Figure 2-1 show,The marked No. 3 port is USB communication port, NC200 communicate with mach 3 through it. - 9 -...

  • Page 12: Chapter 3. Software Installation

    Manual of NC200 Chapter 3. Software Installation 3.1 MACH3 Install MACH3 installation, registration, and USB plug-ins. See as Figure 3-1 Figure3-1. MACH3 soft installation First run the installation Mach3Version3.043.066 .Into the first page. See as Figure 3-2. - 10 -...
  • Page 13 Manual of NC200 Figure3-2. MACH3 installation process 1 Click Next and then enter the page shown in Figure 3-3 Figure3-3. installation process Select I agree and click Next，See as Figure 3-4. - 11 -...
  • Page 14 Manual of NC200 Figure3-4. MACH3 installation process Select the installation path, click Next (it can be installed on any disk, and recommended to install the C drive or the D drive) See as Figure 3-5 Figure3-5. MACH3 installation process Click Next until completion.

  • Page 15: Nc200 Plug-In Installation

    Manual of NC200 3.2 NC200 Plug-in installation Copy the file NC200.dll to X:\Mach3\PlugIns ， X is the disk where the soft is installed. - 13 -...

  • Page 16: Chapter 4. Setting Of Software

    2.0a Then press OK. If you do not want 。 to the dialog box appear again next time, you can select Don’t ask me this again.If connect successfully,Status bar will show “NC200 device is connected to your computer”. See as Figure4-2. - 14 -...

  • Page 17: Software Common Settings

    Manual of NC200 connect successfully Figure4-2. 4.2 Software Common settings 4.2.1 Check NC200 plugin Click config plugins to input PluginConfig,you can seeNC200. See as Figure4-4. Figure4-3. Input Config plugins - 15 -...
  • Page 18 Manual of NC200 Figure4-4. MVUM Plugin 4.2.2 Motor operating parameters setting Figure4-5. Motor operating parameter setting menu entry See as Figure 4-5.From submenu “motor tuning” of the menu “config” into the motor parameter settings dialog. See as Figure 4-6...
  • Page 19 Manual of NC200 Figure4-6. Motor operating parameter settings dialog The parameters are defined as follows: teps per Pulse equivalent ,it is number of pulses required with axial movement 1mm, This ： can be calculated by lead screw pitch and motor drive segment. Such as pitch 2.5mm,2-phase motor 8 segments, Calculation method is 8*200/2.5=640...
  • Page 20 Manual of NC200 Figure4-7. Port setting intry See as Figure 4- ， 7 Click the sub-menu “ports and pins” of menu “Config” into Port Settings dialog box. Figure4-8. Pin&Port Dialog The sub-pages you need to set include “Motor Outputs”, “Input Signals”, “Output Signals”...
  • Page 21 Manual of NC200 To make the Z axis to the same direction, Z axis’s “Dir low” should be set to”√”.Other axes’s should be set as system need. Attention spindle's PORT is PORT2. Figure4-9. Stepper motor port settings dialog Click “Input Signals” Into the input signal settings page. See as Figure4-10.Here LPT prot 10-13 were configured as X++,HOMEX,Y++,HOMEY.
  • Page 22 Manual of NC200 Function include XYZABC6axis’s Upper and lower limit 、 XYZABC6axis’s HOME point. Figure4-11. Estop Probe and index Setting dialog PROBE ESTOP and Spindle speed back index Setting see as Figure 4- ， 、 Click “Spindle Setup” switch to the spindle settings page. See as Figure4-12.
  • Page 23 Manual of NC200 page see as figure 4-9, we set PWM to PIN1. Attention all output's PORT# is 2. Figure4-13. Spindle setting corresponds to the output configuration - 21 -...

  • Page 24: Chapter 5. Using Of Software

    Manual of NC200 Chapter 5. Using of software 5.1 Set Machine Coordinate system Firstly Open the software,as the drawing 5-1 shows,at this time,the software can operate the machine movements,but before the setting machine coordinate system,there is no connection between the software and machine.So first step is to set the machine coordinate system.
  • Page 25 Manual of NC200 orginal point direction, × means searching original point at negative direction; √ means searching original points at the positive direction.As the pincture 5-3 shows,X axis’s original position is at the negative direction,Y and Z’s original points are at the positive direction.

  • Page 26: Set Workpiece Coordinate System

    Manual of NC200 As Figure 5-3 shows,this page also can set machine soft limit points,Soft Max is positive direction soft limited points,soft Min is negative direction soft limited points.The soft limited points values is according the references to the machine coordinate system,so as this example shows,Y and Z axis’s max value is 0,all the effective coordinate data is less than 0.As the Figure...
  • Page 27 Manual of NC200 one or more workpiece coordinate system. 1 Move to current working piece 0 point 、 Firstly hold down the material,use keyboard or pendant to move tool tip at the 0 point,so this 0 point is the working piece 0 point,it related with the working G code file,so the user must be very familiar to his own working G code.As our example shows,the 0 point is on the center of the...

  • Page 28: Open G Code File And Run

    Manual of NC200 Figure5-6. Main Screen after ZERO all axis 5.3 Open G code file and run As Figure 5-7 shows,press “load G code” botton at the main page or open “Load G code” at main menu “File”,open your G code.It displayed as Figure 5-8 showing,then press button “cycle start”...
  • Page 29 Manual of NC200 Figure5-7. Press Load G-Code and open your G code Figure5-8. After opening G code,press “Cycle Start” and start to work - 27 -...
