Novusun CNC NVCM Series Manual page 11

4
5
6
7
8
9
10
11
12
13
14
15
2.2.6 Universal output interface 2
As the Figure 2-2 show, The marked No. 6 is Universal output interface 2. This port type
is DB15. OUT5-OUT16 are fixed on this port. Internal structure see as Figure2-6. Definition see
as table 2-2.
Manual of NVCM
WHB+
XIN
ZIN
X100IN
EP
R1IN
GND
WHA-
WHB-
YIN
AIN
X10IN
Table 2-1. MPG port definition
Internal structure
Figure2-6.
B phase negative of the encoder
X axis select input
Z axis select input
100 rate select input
Estop port
RXD of Serial port(only for NVMPG)
Ground and common end
A phase positive of the encoder
B phase negative of the encoder
Y axis select input
A axis select input
10 rate select input
of output interface
- 9 -
