- Page 1 百年品质，值得信赖 —— 您的产品名称 CNC CONTROLLER BOX NCB01 Manual WWW.NVCNC.NET WWW.NVCNC.NET...
-
Page 2: Table Of Contents
Manual of NCB01 WWW.NVCNC.NET 请在这里输入您的公司名称或产品名称 Contects Chapter 1. Brief Introdution .......................... - 1 - 1.1 Products brief introduction ........................- 1 - 1.2 Specification feature ..........................- 1 - 1.3 Product appearance and dimension ......................- 1 - 1.4 Notice and Waring ..........................- 5 - ... -
Page 3: Chapter 1. Brief Introdution
Brief Introdution 1.1 Products brief introduction NCB01 is designed for CNC Amateur. It's a total solution. You only need mechanical part of CNC machine, connect with NCB01 to constitute a system. NCB01 is compatible with mach3 by LPT. Using NC200,NCB01 connect with mach3 by USB. - Page 4 Manual of NCB01 WWW.NVCNC.NET Figure1-1. NCB01 appearance 1 Figure1-2. NCB01 appearance 2 - 2 -...
- Page 5 Manual of NCB01 WWW.NVCNC.NET Figure1-3. NCB01 appearance 3 Figure1-4. NCB01 connect with NC200 - 3 -...
- Page 6 Manual of NCB01 WWW.NVCNC.NET Figure1-5. NCB01 connect with NC200 & NHC NCB01's product outline dimension is 118*76*33mm,as picture 1-6 shows. - 4 -...
-
Page 7: Notice And Waring
Manual of NCB01 WWW.NVCNC.NET Figure1-6. product outline dimension of NCB01 1.4 Notice and Waring Prohibit staying in the rain, it will cause short-circuit.. Pls use proper voltage power supply and motor. Note the power supply connection. Prohibit reverse connection of power supply . -
Page 8: Chapter 2. Connection
Manual of NCB01 WWW.NVCNC.NET Chapter 2. Connection 2.1 Connection interface definition Definition of NCB01.see as Figure 2-1. - 6 -... -
Page 9: Detailed Definition
Manual of NCB01 WWW.NVCNC.NET Figure2-1. NVBDH+panel button speed control+ Panel start/stop control Mark Definition Spindle Control Panel Estop Button Parallel Control Port Limit Port X axis Steppermotor Port Y axis Steppermotor Port Z axis Steppermotor Port A axis Steppermotor Port... - Page 10 Manual of NCB01 WWW.NVCNC.NET driver's mode. See as manual of NVBD 2、Estop Button This button is Estop button. When in an emergency, you can push this button. Estop button is connected to PIN15 of LPT. Set of ESTOP see as Figure 2-2.
- Page 11 Manual of NCB01 WWW.NVCNC.NET Dir of Y axis Step of Z axis Dir of Z axis Step of A axis Dir of A axis LIMITX+/HOMEX LIMITY+/HOMEY LIMITZ+/HOMEZ Probe, adjust the tool M3,Spindle Start/Stop switch port ESTOP SWITCH1 SWITCH2 18-25 Table 2-2 Definition of LPT port 4、Limit Port...
- Page 12 Manual of NCB01 WWW.NVCNC.NET Figure2-3. Pin number of LIMIT Port Definition of Pin see as Table 2-3 Mark Definition LPT number LIMITZ/HOMEZ PIN12 LIMITY/HOMEY PIN11 LIMITX/HOMEX PIN10 Table2-3 Pin Definition of LIMIT PORT Set of mach3 see as Figure 2-4. In this configuration LIMIT and HOME share a input PIN.
- Page 13 Manual of NCB01 WWW.NVCNC.NET switch type is SN04-N. Connection of LIMIT PORT and Normal micro switch see as Figure 2-6. Figure2-4. Set of LIMIT in mach3 - 11 -...
- Page 14 Manual of NCB01 WWW.NVCNC.NET Figure2-5. Connection of LIMIT PORT and NPN Proximity switch - 12 -...
- Page 15 Manual of NCB01 WWW.NVCNC.NET Figure2-6. Connection of LIMITI PORT and Normal switch 5-8、X/Y/Z/A axis Steppermotor Port These 5-8 port are setppermotor port. Pin number of these port see as Figure 2-7. PIN - 13 -...
- Page 16 Manual of NCB01 WWW.NVCNC.NET Definition of these port see as table 2-4. Set of Mach3 see as Figure 2-8. Pay attention to DIR of X axis, Dir Low active of DIR Z axis should be set to "√". Figure2-7. Pin No. of Steppermotor Port...
- Page 17 Manual of NCB01 WWW.NVCNC.NET Figure2-8. Set of Mach3 about steppermotor Port 9、Programmable Output Port This port is 2 relay output. They are 2 switch which can be controlled by mach3. Pin number of this port see as Figure 2-9. Pin definition of this Port see as table 2-5.
- Page 18 Manual of NCB01 WWW.NVCNC.NET Mark Definition LPT PIN SW2-A SW1-A SW2-K SW1-K Table 2-5 Pin definition of Programmable output port Take SW2(PIN17) as an example, see as Figure 2-10 outside circuit connect to this port. Figure2-10. Programmable Port Connection - 16 -...
- Page 19 Manual of NCB01 WWW.NVCNC.NET Configuration of mach3 see as Figure 2-11. Figure2-11. Configuration of mach3 about P-Port. 10、Probe Port Probe port is set PIN13 in LPT port. Connection method see as Figure 2-12. Probe Configuration of mach3 see as Figure 2-13.
- Page 20 Manual of NCB01 WWW.NVCNC.NET Figure2-12. Connection method of Probe Figure2-13. Probe Configuration of mach3. 11、Spindle Port Pin number and definition see as Figure 2-14. In Spindle Controller panel,P0 set to 1,P1 - 18 -...
- Page 21 Manual of NCB01 WWW.NVCNC.NET set to 1,P2 set to 1. Other Parameter no need to change. Spindle set in mach3 see as Figure 2-15. Figure2-14. Pin number of Spindle Port. - 19 -...
- Page 22 Manual of NCB01 WWW.NVCNC.NET Figure2-15. Spindle set in mach3. 12、AC power Input Port This Port need to supply 220VAC/10A Power. This is a standard Port. 13、Main Power Switch - 20 -...
- Page 23 Manual of NCB01 WWW.NVCNC.NET Take the switch to "-",main power is turned on. Take the switch to "o" main power is turning off. 14、Spindle Power Switch Take the switch to "-",spindle power is turned on. Take the switch to "o" spindle power is turning off.
