Figure 3-2: Connector Locations
2
A B ( P10 and P9 )
P10 is used to connect towards the slave board and P9 is used to connect towards the master board. These connec-
tors allow the AD2428 on the eval board to talk to other A
Part Description
2-pin DuraClik
DuraClik cable assembly

A2B Interface( P1 )

2
The A B Interface is a high speed connection that allows connecting the ADZS-AD2428MINI to other boards,
such as the ADZS-EZKIT-SOM. This connector brings out the signals for I2S, TWI, SPI, GPIO, 1.8v power, 3.3v
power, VBUS and also is +12v input for the ADZS-AD2428MINI.
The following table contains the pinout for the A2B Interface high speed connector:
Signal Pin Pin Signal
GND 1 2 GND
ADZS-AD2428MINI Manual
Manufacturer
Molex
Mating Cable
2
B devices on the bus.
Part Number
5023520200
Connectors
3–3
