A2B Breakout Header( P2 ) - Analog Devices ADZS-AD2428MINI Manual

Signal Pin Pin Signal
GND 69 70 GND
SPI_CLK 71 72
GND 73 74 GND
~SPI_SS1 75 76
GND 77 78 GND
~SPI_SS2 79 80
GND 81 82 GND
I2C_SDA 83 84
GND 85 86 VOUT1
I2C_SCL 87 88 VOUT2
GND 89 90 GND
GND 91 92 GND
GND 93 94 GND
A2B_VBUS 95 96 VBAT_IN
A2B_VBUS 97 98 VBAT_IN
A2B_VBUS 99 100 VBAT_IN
Part Description
A2B High Speed Interface
LSS-150-01-L-DV-A-K

A2B Breakout Header( P2 )

The A2B Breakout Header is a 0.1" connection that allows connecting the ADZS-AD2428MINI to other boards,
such as the ADZS-EZKIT-SOM. This connector brings out the signals for I2S, TWI, GPIO, 1.8v power, 3.3v pow-
er, VBUS and also is +12v input for the ADZS-AD2428MINI. It can also be used for probing or wiring in other
evauluation boards or custom designs.
Signal Pin Pin Signal
GND 1 2 GND
BLCK 3 4 IO7
GND 5 6 GND
SYNC 7 8 IO2
GND 9 10 GND
ADZS-AD2428MINI Manual
Manufacturer
SAMTEC
Mating Connector
Part Number
LSS-150-01-L-DV-A-K
Connectors
3–5
