Figure 3-4: LED Locations
A2B IO1 & IO7 LED ( DS3 and DS1 )
2
The A
B IO1 and IO7 signals are connected to LEDs on the ADZS-AD2428MINI. Refer to the HRM for further
info on using interrupts.
2
A
B Interrupt ( DS2 )
2
The A
B interrupt LED is driven by the AD2428 (add link). The LED is turned on when the IRQ pin drives it
high. Refer to the HRM for further info on using interrupts.
ADZS-AD2428MINI Manual
LEDs
3–9
