Alpha-Link 8-Rmp - Solid State Logic C100 HDS Installation Manual

Connector Pinouts
A -L 8-RMp
LpHA ink
Microphone inputs 1–12
Location:
Connector Type:
Pin Description
1 Ground
2 + signal
3 – signal
Analogue output 1–8
Location:
Connector Type:
Cct Hot
1 24
2 10
3 21
4 7
5 18
6 4
7 15
8 1
A -L L
LpHA ink iVe to
RJ45 Plug
1
2
3
4
5
6
7
8
*Applicable to Alpha-Link Live only. Alpha-Link Live-R can use pin-pin Ethernet compatible cables
Page 4-12 | Section 4 – Appendices
MIC/LINE IN 1 MIC/LINE IN 2
1
2 2
3
Alpha-Link 8-RMP Rear panel
XLR 3-pin female
Notes:
Alpha-Link 8-RMP rear panel
25-way D-type female
Cold Screen
12 25 Pin 13 unused
23 11
9 22
20 8
6 19
17 5
3 16
14 2
A -L 8-RMp c
LpHA ink
MIC/LINE IN 3 MIC/LINE IN 4 MIC/LINE IN 5 MIC/LINE IN 6 MIC/LINE IN 7
1 1 1 1 1
2 2 2 2
3 3 3 3 3
Notes
c p
ontRoL ABLe
RJ45 Plug
1
2
3
4
5
6
7
8
CONNECT TO
PORT NUMBER
MIC/LINE IN 8
LINE OUT 1 – 8
1 1
2 2
3 3
*
inoUt
C100 HDS Installation Manual
POWER
ALPHA-LINK
