a -L L
LPHa ink
Connect the sync sources as described on page 3-3.
Refer to page 4-11 for the connector pinouts.
i
F c
ibre abLeS
2m fibre cables are supplied with each Alpha link Live-R which can be used for initial testing or if the units are adjacent to
the Blackrock processor.
It is the responsibility of the facility or system integrator to supply longer fibre cables that may be necessary to allow the
Alpha-Link units to be remotely located.
Each unit will require one or two fibre cable runs depending on the method of connection to the Blackrock. The diagrams
opposite show the different connection arrangements.
• Cable specification is: 50/125µm, multimode, duplex LC (at the Blackrock) to SC (at the Alpha-Link).
• Singlemode 9/125µm cables cannot be used.
• It is recommended that spare cables are run to remote units to allow for damage or future expansion.
Suitable cables are readily available from networking and computer supply outlets.
a i/o
naLogue
Balanced analogue inputs and outputs are available via the D25 connectors. Each connector provides eight channels.
D i/o
igitaL
Four input circuits and four output circuits of 110
appropriately matched 110
Digital channels 1–4 feature SRC conversion on their inputs. All other digital inputs operate at the system sample rate.
u D
nbaLanceD igitaL
A 1U, 32-channel, BNC converter/breakout panel is available for the connection of 75
Panels can be ordered with either 1m or 3m connection cables. Note that 3m is the maximum distance at which the panel
can be located.
8-rmP r
emote
For remote control connection to separate Alpha-Link 8-RMP microphone amplifier units. See following pages.
C100 HDS Installation Manual
-r
ive
cable for the connection of digital equipment.
i/o
balanced AES/EBU are provided on each connector. Use only
Section 3: Installation
Alpha-Link Live-R
unbalanced digital equipment.
| Page 3-11
