Specifications
S
pecificAtionS

c100 HdS console

Parameter
Height
Height adjustment
Width
Depth
Weight
Heat Dissipation
Voltage
Current
Power Factor
Fusing
Noise
Connectors
Page 4-2 | Section 4 – Appendices
Condition
To top of meter trim
32 channel without side trim
8 channel bay (add/subtract)
Contoured side trims
32 channel console with two legs
8 channel bay (add/subtract)
Additional Leg
32 channels
8 channel bay (add/subtract)
Range
32ch max. over voltage range
48ch max. over voltage range
No user-accessible fuses
Fanless
Power in Main/Backup
Network TCP/IP
USB (touchscreen)
Meter input Analogue
Meter input Digital
T/B audio output
Value Unit
1,006 mm
-0 +10 mm
1,431 mm
285 mm
+72 mm
926 mm
123 kg
26 kg
6.5 kg
400 W
80 W
100 – 240 V
3.2 – 1.3 A
5.1 – 1.9 A
0.95
IEC 3-pin male 10A
RJ45 100 baseT
USB A
25-way D-type male
25-way D-type female
XLR 3-way male
C100 HDS Installation Manual
Notes
Add 36mm each side
Additional 18mm for heatsinks
Approximately
"
"
Approximately
"
±10%, AC only
Approximately
