Connector Summary - Solid State Logic C100 HDS Installation Manual

a -L 8-rmP
LPHa ink
The RMP provides 8 microphone amplifiers in a 2U high 300mm deep 19" rack unit. It features dual power supplies for
on-air reliability. Switchable phantom power is available on each input.
The 8-RMPs connect directly to an Alpha-Link Live unit, not to the Blackrock processor. Up to three units can be
controlled by each Alpha-Link Live.
Outputs from the 8-RMP are at line level and should be connected to the Alpha-Link Live using 8-circuit balanced audio
cable.
Remote control information is provided by a separate RJ45 data cable.* Pairs of audio-plus-control cables can be ordered
from SSL in lengths of 1m, 5m, 10m and 25m. Cable pinouts are listed in the appendices. The maximum recommended
cable length between each Alpha-link 8-RMP and an Alpha-Link Live is 50m.
c S
onnector ummary
Name Connector
Mic/Line In XLR3 F
Line Out D25 F
Remote RJ45
*Standard Ethernet cables can be used to connect to Alpha-Link LIVE-R. Custom pinout is required to connect to Alpha-Link Live.
i See Section 4-12 for the connector pinouts.
C100 HDS Installation Manual
Description
Microphone input. Pin 2 +ve. Switchable phantom power.
8 channel balanced audio outputs, line level.
Control data connection to Alpha-Link LIVE-R.*
System Components
Section 2: Preparation | Page 2-23
