S o
yStem PtionS
S t
criPt ray
The script tray is an 8-channel wide movable transparent panel which fits over a channel bay. It has rollers fitted to allow
it to move along the length of the desk.
The script tray does not require modifications to the console and can be added to existing consoles.
L S
ouDSPeaker HeLF
A flat secure shelf is available for the positioning of loudspeakers, monitors etc. Each shelf is 400mm wide by 253mm deep.
A shelf is securely attached by locating under the front of the top trim and then screws are used to fix to the console's
back panel.
S a t
iDe rm rim
Standard side panels of the consoles are flat to simplify the positioning of adjoining furniture. A smooth contoured arm in
contrasting silver finish is available which can be attached to the side panels to provide a more comfortable and attractive
finish
tFt e i
xternaL
This option adds an input switcher to any of the channel bay TFT screens so that it can then be switched to display the
signal from an external XGA (1024x768) video input. The switchover may be effected either by a GPI closure triggered
from a free button or by one of the unused latching switches located on the meter panel (see page 43).
Because it is necessary to install additional hardware within the console frame when adding this option, a maximum of
three of the four channel screens on the 32-channel console can be modified.
m u
uLticHanneL
Space is available in the console centre section into which a multichannel LCD meter can be fitted. Two types available to
order: RTW Touchmonitor TM-7 (8ch analogue plus 8ch digital) or the MSD600M (8ch digital as standard but modular
and customisable). Both phase-scopes feature loudness metering as standard.
