Console Connectors - Solid State Logic C100 HDS Installation Manual

c c
onSoLe onnectorS
1
T O
XLR-3 male
ALkbACk uT
The centre control tile of the console is fitted with a talkback microphone. The output signal is analogue, balanced and at
approximately 0dBu.
i
2
vu M P
ETERS PLuS
VU meter inputs. If a phasescope with analogue inputs has been specified then this connector will also supply the meter's
analogue inputs.
3
P D
HASESCOPE IgITAL
Phasescope digital inputs. Pinout will depend on which model of phasescope is chosen. For both the RTW and DK meters
a D9 diagnostic/terminal connector will also be fitted.
*Both connectors are only fitted if a phasescope has been specified.
4
SSL N C
ETWORk ONNECTIONS
These connectors link the console to its Blackrock processor(s). Standard Ethernet cables can be used.
5
T k
OuCHSCREEN EybOARD
For the connection of an external USB keyboard as a method of text entry as an alternative to the touchscreen. An infra-
red wireless combined keyboard/trackball is included as standard. The keyboard's IR receiver will need to be located above
the console's top trim.
6
T vgA O
OuCHSCREEN
Mirrored video output of the centre section touchscreen. Can be connected to an external XGA monitor for backup or
training purposes (note that the display is in portrait orientation).
7
RS422 S P
ERIAL ORTS
Two 9-pin serial ports are available for the connection of 3rd party equipment to provide router naming and automation
control. Automatic control backup will be included on systems that are equipped with processor redundancy. Allocation
of function is setup in system software.
C100 HDS Installation Manual
Page 3-23.
A I
HASESCOPE NALOguE N
I D25 female* / D
N IAgNOSTICS
RJ45
/M USB
OuSE
HD15F
uTPuT
D9 male
Page 3-27.
i
a
DDitionaL
#
#
# 5 x blank for user option
D25 male
D9 female*
Page 3-23.
i
i Page 3-27.
c P
onnector aneL
#
7
#
RS422
Serial 2
System Components
#
6
RS422 Touchscreen
Serial 1 VGA Out
Section 2: Preparation
Page 3-5.
i
| Page 2-15
