Solid State Logic C100 HDS Installation Manual page 31

b c
Lackrock onnectorS
1 2
& SbC vgA/M
Optional keyboard input and XGA monitor connection to the internal SBC Linux PC. A connection will only be required
during initial system configuration and if network computer is available.
3
TCP/IP N
ETWORk
Should be connected to file management PC over the facility's Ethernet network. Must be kept separate from the SSL
network. Page 3-5.
i
4 5
& SSL N
ETWORk
Both internal processors, the SBC and the DSP, must be linked and connected to the console surface using the inbuilt hub.
Redundant systems and those with additional peripherals or a MORSE router will also require the addition of a 3rd party
network router so that all items can connect to the SSL network.
6
MIDI RJ45
IP
Separate Ethernet connection to facilitate communication with a suitably equipped DAW.
7
S I 75 BNC
yNC NPuT
Input for system reference. A sync reference common to all equipment will be required if using digital peripherals. The
input is not internally terminated and must be fitted with the external tee-piece and terminator provided (sync must not
be daisy-chained between units).
8
RS422 S P
ERIAL ORT
The serial port can be assigned to either the transfer of router names using Probel protocol or as the interface to
ROSS/Sony protocol remote controllers (cost option). pinouts.
9
F I/O P
Duplex LC
IbRE ORTS
Fibre interface ports for the connection of remote I/O units. Four ports are supplied as standard – each fitted with a
multimode duplex LC fibre interface adapter. A second four port card can be specified (as shown opposite) to provide
additional I/O capacity.
The standard MADI ports support 64 audio channels, either individually or as two redundant pairs. Blacklight links (RIO
only) support 256 audio channels – configured as two redundant pairs.
C100 HDS Installation Manual
HD15F USB
OuSE
RJ45
RJ45
i Page 3-3.
D9 male
i Page 3-5.
i Page 3-27.
Section 2: Preparation
System Components
Page 3-29.
i
| Page 2-19
