F
ibre cabLeS
Fibre optic cabling will be required between the Blackrock processor(s) and each outboard I/O Unit – RIO, Alpha-link
LIVE-R, SDI-MADI and MORSE units all use duplex fibre for audio interfacing. Redundant systems will require two
individual fibre links to each outboard unit; see the examples on the following page.
The Alpha-Link 8-RMP microphone amplifiers do not require audio fibre connection to Blackrock. They connect to a local Alpha-
Link LIVE-R unit using analogue and network cabling.
It is a sensible practice to install spare cable runs to allow for system expansion or to replace any leads that may subsequently
become damaged.
The table below lists the cable and connector requirements.
F C
IbRE ONNECTORS
Source
Blackrock
Blackrock Alpha-Link LIVE-R
Blackrock
Blackrock MORSE Stagebox
Blackrock
MORSE Router MORSE Stagebox
* MORSE units are fitted with multimode adapters as standard. Singlemode interfaces are available to special order only and will
have extended lead-times.
F S
ibre tanDarDS
The default interface fibre interface adaptors fitted are suitable for multimode fibre connections. RIO stageboxes and
MORSE units may optionally be ordered with singlemode versions for any of the fibre links. (The corresponding port on
the Blackrock processor must also be changed to singlemode.) Alpha-Link LIVE is only available with multimode interfaces.
All SSL fibre interfaces use flat (PC) termination not angled (APC).
Singlemode and multimode interfaces and connectors are almost identical in appearance, however, they are operationally
incompatible – the two different standards cannot be mixed for any individual link.
The table below lists the fibre interface standards available and the maximum cable lengths permissable.
Data Type
MADI
"
"
Blacklight
"
"
C100 HDS Installation Manual
Destination
RIO MADI or Blacklight
MORSE Router
SDI–MADI I/F
Fibre Type Specification
Multimode 50/125um
Multimode 62.5/125um
Singlemode 9/125um
Multimode 50/125um
Multimode 62.5/125um
Singlemode 9/125um
Data Type Connectors
MADI
MADI
MADI
MADI
MADI
Maximum Length
550m
<300m
2,000m
300m
150m
2,000m
System Components
Standard
LC – LC Multimode or Singlemode
LC – SC Multimode
LC – SC Multimode or Singlemode*
LC – SC Multimode or Singlemode*
LC – ST Multimode
SC – SC Multimode or Singlemode*
Note
Default fitment
No longer available
Option
Default fitment
No longer available
Option
Section 2: Preparation | Page 2-9
