Wire the Zone Terminals

Terminals 8 through 12 connect grounded zones 1 through 3. These zones have
a grounded side and cannot be used for fire‑initiating devices. Zones 2 and
3 can also be used for access control with zone 2 providing a bypass feature and
zone 3 providing request to exit functionality.
Terminals 13 and 14 connect to zone 4. Zone 4 provides a non‑powered Class B
ungrounded zone suitable for connection to fire devices such as heat detectors or
pull stations.
Note: You must provide a mechanical means of resetting four‑wire smoke
detectors or other latching devices on zone 4. The panel does not drop power
to the Keypad Bus or AX‑Bus when a Sensor Reset is performed.
Use the supplied 311 1k Ohm End‑of‑Line (EOL) resistors on each zone. Refer to the
panel programming guide for programming instructions. See Table 1 and Figure 8 for
more information on wiring the zone terminals.
Digital Monitoring Products, Inc.
|
734INT Installation and Programming Guide
9
