Mount the 734INT

The module comes in a high‑impact plastic housing that you can mount directly to a
wall, backboard, or other flat surface.
For easy installation, the back and ends of the 734INT housing have wire entrances.
The back also contains multiple mounting holes that allow you to mount the module
on a single‑gang switch box. DMP recommends mounting the 734INT near the
protected door. Refer to Figure 2 for mounting hole locations on the housing base.
1. Remove the PCB from the
plastic housing by loosening
the clips on one side and gently
lifting it out of the housing base.
2. Insert the included screws in the
desired mounting hole locations
and tighten them to secure the
housing to the surface.
3. Reinstall the PCB in the housing
base.
4

INSTALL THE 734INT

734INT Installation and Programming Guide
Mounting Holes
Figure 2: Mounting Hole Locations
