ACTIVATE ZONE 2
BYPASS? NO YES
Digital Monitoring Products, Inc.

ACCESS OPTIONS

Activate Zone 2 Bypass
Select YES to activate the zone 2 bypass operation. Selecting
NO allows standard zone operation on zone 2. The default is
NO.
If the door being released by the 734INT module is protected
(contact installed), a programmable bypass entry/exit timer
can be provided by connecting its contact wiring to module
zone 2. When the onboard Form C relay activates and
the user opens the door connected to zone 2, the zone is
delayed for the number of seconds programmed in ZONE
2 BYPASS TIME allowing the user to enter/exit during an
armed period.
If zone 2 does not restore (door closed) within the
programmed time, the piezo sounds every other second
during the last ten seconds. If zone 2 restores prior to the
end of the programmed time, the piezo silences. If the zone
does not restore before the programmed time, the 734INT
ends the bypass and indicates the open or short zone
condition to the panel.
