NO OF USER CODE
DIGITS:
CARD FORMATS
26 BIT ADDED
Digital Monitoring Products, Inc.
Number of User Code Digits
The 734INT module recognizes user codes from 4‑12 digits
5
long. Press any top row select key or area to enter a user
code digit length. This number must match the user code
number length being programmed in the panel. The device
will recommend a number of user code digits based on the
user code length. Default is 5.
All bits are read and converted into a decimal number string.
The number string is left padded with 0 (zero) if needed for
long user code lengths.
Example:
Card Format Added/Changed (Custom Format)
When a custom card format is added successfully, the
keypad displays xx BIT ADDED, where xx is the Wiegand
code length. When the format is changed, the keypad
displays xx BIT Changed. Press CMD. The menu returns
to "Card Format Number". Program another custom card
format or press CMD to advance to NO COMM WITH PNL.
|
734INT Installation and Programming Guide
# decoded
10 digits
4 digits
1234567
0001234567
4567
29
