DMP Electronics 734N-WIFI How-To Manual

734N-WIFI How-To Programming Instructions
To program a 734N-WIFI, you must complete the programming process in two places: the panel and the 734N-WIFI.
This guide walks you through programming the 734N-WIFI into an XR150/XR550 Series panel and then programming the
734N-WIFI itself.

Program the XR150/XR550 Series Panel

1. Momentarily place a jumper over both pins on the panel's RESET header.
2. Enter the code 6653 (PROG) and press CMD.
3. The keypad displays PROGRAMMER. Press CMD.
4. Press CMD until NETWORK OPTIONS. Press any select key or area.
5. CMD through the options until LOCAL IP ADDRESS is displayed.
6. Write down the LOCAL IP ADDRESS of the panel to use when programming the 734N-WIFI module.
7. CMD through the options until 734N-WIFI LISTEN PORT is displayed.
8. Enter the port number that the 734N-WIFI will use to send communication to the panel. Default is 2002. Write
down the port number, as this must be the same port that is programmed in PANEL IP PORT within the 734N-WIFI
COMMUNICATION programming menu. Press CMD to display 734N-WIFI Passphrase.
Note: The 734N-WIFI LISTEN PORT cannot be the same as the panel network programming port.
9. Enter an 8 to 16-character passphrase to encrypt communication with the 734N-WIFI module. The 734N-WIFI
passphrase must match the 734N-WIFI passphrase entered in COMMUNICATION programming of the 734N-WIFI.
Note: A passphrase is required for communication to occur with the panel.
10. Exit NETWORK OPTIONS and CMD to DEVICE SETUP.
11. Enter the device number of the 734N-WIFI you are programming. For example, a 734N-WIFI with an address of
505 on AX500 would represent Door 505 and zones 505-508. See Table 1 for device addresses and zones.
Note: XR150 Series panels only support addresses 2-8.
Device/
Device/
Door
Zones
Door
501
2 21-24 505
3 31-34 509
4 41-44 513
5 51-54 517
6 61-64 521
7 71-74 525
8 81-84 529
9 91-94 533
10 101-104 537
11 111-114 541
12 121-124 545
13 131-134 549
14 141-144 553
15 151-154 557
16 161-164 561
12. Enter a device name. To add a device name, press any select key or area. The default device name (DEVICE x)
displays. Select CMD to accept the default name or press a select key or area to enter a new name (up to 32
alphanumeric characters). Press CMD when finished.
13. Based on the device number, the DEVICE TYPE may be assumed. Device 501 or higher will automatically be
selected as a DOOR device type.
14. For DEVICE COMMUNICATION TYPE, select the blank select key or area and then select NETWORK.
15. Exit DEVICE SETUP. CMD through options until STOP. Exit programming.
LT-1228 © 2017 Digital Monitoring Products, Inc.
HOW-TO INSTRUCTIONS
Table 1: Device Addresses and 734N-WIFI Zone Numbers
Device/
Zones
Door
501-504 601 601-604
505-508 605 605-608
509-512 609 609-612
513-516 613 613-616
517-520 617 617-620
521-524 621 621-624
525-528 625 625-628
529-532 629 629-632
533-536 633 633-636
537-540 637 637-640
541-544 641 641-644
545-548 645 645-648
549-552 649 649-652
553-556 653 653-656
557-560 657 657-660
561-564 661 661-664
