When you program a 734INT, you can use a keypad connected to the 734INT
programming header and set to address 1. For 12 V applications, connect the keypad to
the module using a Model 330 4‑wire harness. For 24 V applications, connect the keypad
to the module using a Model 330‑24 4‑wire programming harness with in‑line resistor.
Caution: Do not connect a keypad using a standard Model 330 harness if using a
24 V power supply! Damage to the keypad could occur.
You can also program the 734INT from an XR150INT/XR550INT Series panel. If you
choose to program the 734INT from the panel, all future programming should be
performed through the panel. The panel's programming overrides any programming
performed from a keypad connected to the 734INT. While the 734INT is in programming
mode, it will not be able to communicate with the panel.
