User Manual
9d24 Mkll Cordless Telephone
2.5.9

Alpha Numeric Keys

In some applications you have the possibility to write letters as well as numbers, which is
indicated by the "ABC" icon. Pressing the numerical keys will now give you access to the
alphabet plus some special characters according to the picture beneath
- ? ! , . : " ' ( )1
G H I Ï Ì Î Í 4
P Q R S ß 7
Switch between upper
and lower case
In Stand-by Mode
In stand-by mode short presses on the keys enter the digits and the characters * and #.
A long press on a key "0" - "9" activates the programmed Hot key function.
In Text input Mode
In text input mode a press on a key displays the first available character on that specific
key. Continue pressing the key to view the following characters. The marked character is
selected after a time out or when another key is pressed. Press the *-key to switch
between upper case and lower case. A long press in text input mode will give the number.
2.6

Accessories

2.6.1

Belt Clip, Swivel-type

The ordinary belt clip can be replaced with a special swivel-type belt clip adapted to firmly
place your handset onto your belt.
2.6.2

Leather Casing

The leather casing is especially designed for the handset. The casing comes with a swivel-
type belt clip and the handset is fully operational while placed in the casing. The leather
casing can easily be modified for use with handsets equipped with pull-cord alarm.
2.6.3

Headset

A headset is recommended if you frequently use the phone and/or want to have both
hands free. The handset has a special headset connector that is waterproof. The headset
comes in three versions; with microphone integrated in the cable, with microphone on a
boom and with hearing protection (Peltor). An adapter, that makes it possible to connect
other standard types of Peltor headsets, is also available.
2006-03-20/ Ver. PA8
PRELIMINARY
A B C Å Ä Æ À Á Â Ã Ç 2
Space + & @
/ $ % £ \ ± ½ 0
TD 92333GB
.
D E F È É Ê Ë 3
J K L 5
M N O Ñ Ö Ø Ò Ó Ô Õ 6
T U V Ü Ù Ú Û 8
W X Y Z Ý 9
# * < = > ^ _ ˚ µ ¿ §
