9.4

Field Upgrade

The 9d24 MkII Messenger and 9d24 MkII Talker can both be upgraded. The 9d24 MkII
Messenger can be upgraded to a 9d24 MkII Protector and the 9d24 MkII Talker can be
upgraded to a 9d24 MkII Messenger or a 9d24 MkII Protector. Specific upgrade packages
have been created and are available for ordering.
The 9d24 MkII EX-Messenger can not be upgraded to 9d24 MkII EX-Protector.
9.4.1

Upgrade

When you have received the upgrade package, download a licence code from our
Extranet and upgrade your handset as follows:
1 Use your handset and enter the upgrade mode: Select the Settings tab
press Navigation key
. Press Navigation key
Tip: There is a quick access code you can use to enter the upgrade mode directly
without using the menu. The quick access code is #87#.
2 Go to the upgrade service on our Extranet and enter the IPEI number and the access
code for the handset. The IPEI number is shown in your handset when entering the
upgrade mode. The access code is included in the upgrade package.
3 When you have received the licence code, enter the licence code in the upgrade
mode on your handset and press "Ok". A message is shown in the display telling
you if your handset has been upgraded or not. Additional functions have now been
added to your handset. The functions can be used immediately without having to
restart the handset.
4 The upgrade package contains a new top front for the handset. To replace the
existing top front on the handset with the new one, do as follows:
Release the two scews at top on the handset and lift off the top front, see
and
screws, see
Figure 10. Release the two screws at top on the handset.
2007-02-07/ Ver. D
to enter Settings. Mark "System" and press Navigation key
figure 11. Mount the new top front on the handset and fasten it with two
figure 12, figure 13
1
1
and mark "Upgrade". Press Navigation key
and figure 14.
