Call Back; General Purpose Options; Option Shortcut; Messaging - ASCOM 9d24 Mkll User Manual

User Manual
9d24 Mkll Cordless Telephone

3.15.6 Call back

The purpose of this option is to allow users access to call back functionality. If the "Call
back data" parameter in the SIM is programmed, the Call menu will contain the option
"Call Back".
1 Press "Options" during the call
2 Mark "Call back" and press "Select".

3.15.7 General purpose options

The purpose of these options is to allow users to configure the Call menu to provide
access to other exchange functionalities than those described above.
It is possible to program five "general purpose" options. Each such option consists of
"name" and "data". If both name and data (for the same option) are programmed in the
SIM, the option will appear in the Call menu, the name of the option being displayed.

3.15.8 Option shortcut

It is possible to create a shortcut to one of the options in the Call menu. If the SIM
parameters "General SoftKey name" and "General SoftKey data" are programmed and
the data of the option indicated by "General SoftKey data" has a value, then the shortcut
name will appear as the right Soft key in the call screens. When selecting this shortcut,
the option indicated by the "General SoftKey data" will be executed according to the
descriptions above.
This will replace the "R" Soft key while in a call.
4

Messaging

Note: 9d24 Mkll Messenger and 9d24 Mkll Protector only.
4.1

Message List

Up to twenty messages can be stored in the message list (including the queue), if the
total number of characters does not exceed 6000. When the total number of characters
exceed 6000, the oldest stored message is deleted from the list. Press the Navigation key
to enter the message list.
4.2

Receive a Text Message

The flashing LED, accompanied by a message tone and/or a vibrating telephone, gives
you notice of a message. The message tone can be silenced by a press on the Mute
button. The message tone will break trough silent mode if the message is urgent. The
message is shown on the display. The size of the text can be changed, see
Text Size on page 40. The text can also be displayed upside down, see
Messages to be Displayed Upside down
By pressing any key (not alarm, mute and volume buttons) the received message is
marked as read.
2007-02-07/ Ver. D
on page 42.
TD 92333GB
8.5.11 Change
8.5.17 Set New
16
