6 Place the handset in the slave slot to the left of the master slot, see figure below.
Make sure that the handset locks into position. "Erase memory" is shown in the
slave handset display. Then the copying process starts.
Figure 15. Master and slave slots in a CR24 Charging Rack for copying of software.
When "Ok" appears in the bottom of the display the copying is finished.
If the copying was not successful "Fail" will appear in the display. Remove the
handset from the charging rack and repeat from point 4.
7 Remove the handset from the charging rack. "Exit Ok" is shown in the display.
Press volume key up to start up the handset. To continue copying software to
additional slave handsets, keep the master handset in the charging rack and repeat
from point 4.
8 When the copying procedure is finished remove the master handset from the
charging rack. Press volume key up to start up the handset.
9.6

Changing SIM parameters

The SIM card parameters can be altered from the handset but also by using a SIM Card
Programmer. To be able to give the same parameter settings to several handsets the
parameters can be saved to file from the SIM Card Programmer. The file can also be used
to reset the parameters in a handset to default values. The SIM Card Programmer is
delivered with a CD containing required software.
SIM Card Programmer for 9d23 and 9d24
2007-02-07/ Ver. D
Figure 11.
slave master
slot 1 slot 1
slave master
slot 2 slot 2
Art.No: 651041
