Document History
Document Title: AN209375 - Recommendation for Hardware Setup 32-Bit FR81S Family
Document Number: 002-09375
Revision ECN Orig. of
Change
** -
*A 6095053 NOFL
*B 6523608 NOFL
www.cypress.com
Submission
Date
- - Initial release
- RSTX and NMIX input section:
correction RSTX and NMIX input
- obsolete issue removed
- Added new section:
5V-tolerant IOs
01/06/2014 V1.3: FTo
02/11/2015 V1.4: FTo
Modified Figure 1: Principle schematic for minimal requirements and Figure 30:
Principle schematic for serial programming via Usart0 (with USB cable)
03/12/2018 Updated to Cypress template.
Completing Sunset Review.
Replaced "MB" with "CY" in all instances across the document.
03/27/2019
Completing Sunset Review.
Document No. 002-09375 Rev. *B
Recommendation for Hardware Setup 32-Bit FR81S Family
Description of Change
