Cypress MB95FV100D-103 Operation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
2
F
MC-8FX Family
MCU Board for MB95FV100D-103
MB2146-303A,
Operation Manual
Doc. # 002-07490 Rev. *A
Cypress Semiconductor
198 Champion Court
San Jose, CA 95134-1709
Phone (USA): 800.858.1810
Phone (Intnl): +1.408.943.2600
www.cypress.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the MB95FV100D-103 and is the answer not in the manual?

Questions and answers

Related Manuals for Cypress MB95FV100D-103

Summary of Contents for Cypress MB95FV100D-103

  • Page 1 MC-8FX Family MCU Board for MB95FV100D-103 MB2146-303A, Operation Manual Doc. # 002-07490 Rev. *A Cypress Semiconductor 198 Champion Court San Jose, CA 95134-1709 Phone (USA): 800.858.1810 Phone (Intnl): +1.408.943.2600 www.cypress.com...
  • Page 2 Cypress is not liable, in whole or in part, and you shall and hereby do release Cypress from any claim, damage, or other liability arising from or related to all Unintended Uses of Cypress products.
  • Page 3 Warranty and liability disclaimers ■ The specifications of the product are subject to change without notice. In no event shall Cypress be liable for any loss or damages whatsoever directly or indirectly arising out of the use of the product. Product operating environment ■...
  • Page 4 Data Sheet of the MCU used ■ “MB2146-09 BGM Adapter Instruction Manual” ■ Related “Header Board Instruction Manuals” ■ ““S Workbench Operation Manual” OFTUNE ■ “S Workbench USER’S Manual” OFTUNE ■ F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 5 Re-transporting the product may damage it to cause a fault. Keep Damage the packaging materials used for shipment of the product and use them when re- transporting it. F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...

  • Page 6: Table Of Contents

    Contents 1. Product Outline 2. Checking the Delivered Product 3. Connections 4. How to Setup 5. Product Specifications Revision History F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...

  • Page 7: Product Outline

    *2: The header board is an interface board to connect the MCU board to your user system. Choose and pur- chase a type of header board which is applicable to the production MCU to be used. F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 8 (10) BGM adapter connector (11) Header board I/F connector A (12) Header board I/F connector B (13) Evaluation MCU (MB95FV100D-103) (14) Incorrect insertion prevention guard Note used during debugging. F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...

  • Page 9: Checking The Delivered Product

    Before using the MCU board, confirm that the following components are included in the box: MCU board: 1 ■ Operation manual (English version, this manual): 1 ■ Operation manual (Japanese version): 1 ■ F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...

  • Page 10: Connections

    * : Be sure to connect the BGM adapter correctly to the BGM adapter connector (CN3) on the MCU board. It can damage the MCU board if it is accidentally connected to the LVD2 detection voltage selector jumper plug (S2). F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 11 BGM adapter connector on the MCU board. 2. Remove the header board from the MCU board. Remove it with uniform force without applying force to only one point. F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...

  • Page 12: How To Setup

    Setting of the LVD2 detection voltage selector jumper plug (S2)”. Figure 4-1. The switch and jumper plug on a MCU board GND VCC PRODUCT SELECT 1 2 3 4 1 2 3 4 ADAPTER F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 13 F MC-8FX (MB95FV100D and MB2146-09). 2. Do not perform a chip erase when using the software development support environment for the MC-8FX (MB95FV100D and MB2146-09). F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 14 4-1. Figure 4-3. Positions of switches and jumper plugs on the MCU board GND VCC PRODUCT SELECT 1 2 3 4 1 2 3 4 ADAPTER F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 15 (S1)”). LVD2 detection voltage Set the LVD2 detection voltage (See “ Setting of the LVD0 selector jumper plug LVD2 detection voltage selector jumper plug (S2)”). F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 16 Table 4-3. Setting of the sub clock supply source Settings of the clock input selector switch Sub clock supply source SW2-3 SW2-4 Clock area User system F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 17 100-pin package, LCD function integrated type 80-pin package, LCD function integrated type 64-pin package, LCD function integrated type 48-pin, 52-pin package, LCD function integrated type Setting Prohibited F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 18 These settings cannot be used during debugging. Set the jumper to LVD0 to use the debugger. Figure 4-6. The LVD2 detection voltage selector jumper plug (S2) F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 19 Table 4-6. Setting of the LVD2 detection voltage selector jumper plug Jumper plug position LVD2 setting value 4.17V LVD0 3.74V LVD1 3.3V LVD2 2.9V LVD3 2.6V LVD4 F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...

  • Page 20: Product Specifications

    The crystal oscillator mounted socket on the MCU board is used to supply clock Clock mounting socket signals to the main clock (X0/X1) and sub clock (X0A/X1A) pins on the evalua- tion MCU from the MCU board. F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 21 Vcc,GND,BRSTX, connector SEL4 BSIN,BSOUT, BDBMX,BEXCK LVDIN SEL0 LVR0 Product SEL1 LVR1 selector SEL2 LVR2 switch SEL3 LVR3 LVR4 LVD2 detection voltage setting jumper plug Other pins F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 22 Figure 5-2. Clock selector circuit Clock input selector switch Crystal oscillator mounting socket (main Clock) (M1) Crystal oscillator (R1) mounting socket Sub clock selector (sub clock) jumper plug F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 23 (Japan Aviation Electronics Industry, Limited) 2 pin SIP socket Incorrect insertion prevention guard Model number: PCW-3-1-1PW (MAC EIGHT) Spacing between the MCU and header boards when engaged Approx. 5.0mm F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 24 Connects the MCU board to the BGM adapter. Main clock mounting socket Mounts the main clock crystal oscillator. Sub clock mounting socket Mounts the sub clock crystal oscillator. F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 25 Product Specifications Pin assignment of header board I/F connector ■ F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 26 PINT1 PCLK TCLK PADDR0 LVCC * PACTIVE LVDIN PLOCK Cpin PWRITE Vcc51 * PADDR1 LVDENX  GND * PADDR2  LVR4 GND * PADDR3 TESTO PADDR4 F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 27 MCU Pin line MCU Pin line Number Number name Number Number name Number Number name LVDOUT PADDR5 LVR2 PADDR7 BGOEN PRDATA LVR1 PADDR6 PRDATA LVR0 ROMS0 F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 28 PE1A P04B PWDATA PE5A P03B PWDATA PE7A P02B PWDATA PE3B P00B PWDATA PE6A PRDATA Vss * PWDATA  PE2B GND * PWDATA  PE7B GND * F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
  • Page 29 Connect the Vcc51, Vcc53 and Vcc54 pins to Vcc. Disconnect the LVCC pin from Vcc. Connect the Vss pin to GND. Disconnect the LVSS pin from GND. : 5V power supply pins : GND power supply pins F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...

  • Page 30: Revision History

    MC-8FX Family, MCU Board for MB95FV100D-103 MB2146-303A, Operation Manual Document Number: 002-07490 Origin of Revision ECN# Issue Date Description of Change Change  03/13/2007 HUAL Initial release 5299670 06/07/2016 HUAL Migrated to Cypress format F2MC-8FX Family, MCU BOARD for MB95FV100D-103 MB2146-303A, Operation Manual, Doc. # 002-07490 Rev. *A...
