Cypress FM0+ S6E1C SERIES Quick Start Manual

FM0+ S6E1C-SERIES STARTER KIT

• Download and install the FM0+S6E1C-Series

Starter Kit installer FM0PS6E1C3KitSetup.exe

from

www.cypress.com/FM0

FM0-64L-S6E1C3 QUICK START GUIDE

64L-S6E1C3

Kit Contents:

1 FM0+ S6E1C-Series Starter board

2 USB Standard-A to Micro-B cable

3 Quick Start Guide (this document)

www.cypress.com/FM0-64L-S6E1C3

• Check the jumpers J1 and J2 are open

• Check the jumper J4 has been closed on pin 1

and pin 2

• Connect the board with PC via CN3 using the

USB cable

Table of Contents

Do you have a question about the FM0+ S6E1C SERIES and is the answer not in the manual?

Page 1 Kit Contents: 1 FM0+ S6E1C-Series Starter board 2 USB Standard-A to Micro-B cable 3 Quick Start Guide (this document) www.cypress.com/FM0-64L-S6E1C3 • Download and install the FM0+S6E1C-Series • Check the jumpers J1 and J2 are open Starter Kit installer FM0PS6E1C3KitSetup.exe • Check the jumper J4 has been closed on pin 1 from www.cypress.com/FM0...
Page 2 • Press Enter on your PC keyboard to run the the notification area of the taskbar and board test demo select FM-Link/CMSIS-DAP Cypress FM Communications Port • Key in the option 02 and press Enter to • Use IAR Embedded Workbench or Keil uVision...
Page 3 14. Stereo codec 15. Programming mode jumper of FM0+ (J2) 5. Power supply resource select (J4) 6. USB device connector (CN4) 16. Cypress FM0+ MCU S6E1C32D0A 7. Potentiometer 17. RGB LED 8. Programming mode jumper of MB9AF312K (J1) 18. Cypress 4-Mb NOR Flash 9.
Page 4 FM0+ S6E1C-Series Starter Kit NC- Not connected For the latest information about this kit, visit www.cypress.com/FM0-64L-S6E1C3 © 2016 Cypress Semiconductor Corporation. All rights reserved. All trademarks or registered trademarks referenced herein are the property of their respective owners. 002-11420 Rev.*A...
