UG-1461

CONFIGURATION OPTIONS

Table 2. ADMV1013-EVALZ Configuration Options
Component
1.8 V, 3.3_1013, 3.3 V, 5 V, GND
LON, LOP, IF_I, IF_Q, Q_P, Q_N, I_N, I_P, RF_OUT, VENV_N,
VENV_P
R2 to R4, R6, R8
R5, R7
5V, 3.3V, 3.3V_1013, 1.8V, VCTRL1, VCTRL2, GND1
R14, R15, R17, R18, R19, R20, R23, XR6
R1, R13, R16, R22, XR2
C2 to C4, C5, C11 to C31, C34 to C42, C43 to C51, C140,
C141, XC12, XC4 to XC8
JP1 to JP4
C1, R21
XP1
XP2
S1
USB
XU1
U1
U3 to U5
U2
DUT
PCB
1 The ADMV1013-EVALZ evaluation board material between Layer 1 and Layer 2 is made of 10.7 mil Rogers 4350B LoPRo®.
Function
Power supplies and ground
RF data and clock local oscillator
and envelope signal
33 Ω series resistors for SPI pins
1.1 kΩ series resistors for
BG_RBIASx pins
Test points
Shorts or power supply
decoupling resistors
Pull-up or pull-down resistors
Capacitors provide the
required decoupling of the
supply related pins
IQ path configuration
Do not install
Programming header
Mini USB connector
Reset button
Red LED
Microcontroller
Level shifter
3.3 V and 1.8 V regulators
AD5601 nanoDAC
ADMV1013 device under test
1
PCB, ADMV1013-EVALZ
Rev. B | Page 18 of 19
ADMV1013-EVALZ
Default Condition
Not applicable
Not applicable
R2, R3, R4, R6, R8 = 33 Ω (0402)
R5, R7 = 1.1 kΩ (0402)
Not applicable
R17, R18, R19 = 0 Ω (0603), R15 = 100 kΩ (0402),
R14, R20, R23 = 0 Ω (0402), XR6 = 80.6 Ω (1206)
XR2, R1, R13, R22 = 10 kΩ (0603), R16 = 100 kΩ
(0402)
XC4, C4, C13, C16, C19, C22, C25, C28, C31, C36,
C39, C42, C45 = 10 μF (3216), XC12 = 10 μF (0603),
C5, C44, C46, C48, C49, C51 = 4.7 μF (0603), XC5,
XC6, XC7, XC8 = 0.1 μF (0402), C43, C47, C50 =
0.001 μF (0603) C3, C12, C15, C18, C21, C24, C27,
C30, C35, C38, C41 = 0.01 μF (0402), C2, C11, C14,
C17, C20, C23, C26, C29, C37, C40 = 100 pF, C24 =
0.01 μF, C140, C141, XC5 to XC8 = 0.1 μF (0603)
Default: JP1 to JP4 = do not install
IF mode: JP1 to JP4 = do not install
IQ mode: JP1 to JP4 = 0 Ω
C1, R21 = 0402
Not applicable
Connect the mini USB cable to XP2 to interface
with the SPI
Push the reset button to reset the device.
LED is blue when the USB is connected to XP2,
and the PC and the ADMV1013-EVALZ evaluation
board are powered on with a 5 V supply
PIC18F24J50
FXL4TD245BQX
ADM7170 (U3) = 1.8 V regulator,
(U5) = 3.3 V regulator, ADM7172
regulator for ADMV1013
Not applicable
Not applicable
Not applicable
User Guide
ADM7172
(U4) = 3.3 V
