ADSPSC835W-EV-SOM
Manual
Revision 1.0, January 2023
Part Number
82-ADSPSC839W-EV-SOM-01
Analog Devices, Inc.
One Analog Way
Wilmington, MA 01887

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADSPSC835W-EV-SOM and is the answer not in the manual?

Questions and answers

Summary of Contents for Analog Devices ADSPSC835W-EV-SOM

  • Page 1 ® ADSPSC835W-EV-SOM Manual Revision 1.0, January 2023 Part Number 82-ADSPSC839W-EV-SOM-01 Analog Devices, Inc. One Analog Way Wilmington, MA 01887...
  • Page 2 Analog Devices, Inc. reserves the right to change this product without prior notice. Information furnished by Ana- log Devices is believed to be accurate and reliable. However, no responsibility is assumed by Analog Devices for its use; nor for any infringement of patents or other rights of third parties which may result from its use. No license is granted by implication or otherwise under the patent rights of Analog Devices, Inc.
  • Page 3: Table Of Contents

    Manual Contents ............................1–1 Technical Support ............................1–2 Supported Integrated Circuit ......................... 1–2 Supported Tools............................. 1–3 Product Information ............................1–3 Analog Devices Website..........................1–3 EngineerZone ............................. 1–3 Using the Board Product Overview ............................2–1 Package Contents............................2–3 Default Configuration ........................... 2–3 CrossCore Embedded Studio (CCES) Setup ....................
  • Page 4: Preface

    I/O signals. Through the high speed external connector array, the ADSPSC835W-EV-SOM is intended for use with a growing family of SoM carrier products that contain a variety of peripherals to support different applications. The SoM carrier base products that exist today are the EV-SOMCRR- EZKIT and EV-SOMCRR-EZLITE.
  • Page 5: Technical Support

    A companion file in PDF format documenting all of the circuits used on the board is available on the website at http://www.analog.com/ADSPSC839W-EV-SOM. Technical Support You can reach Analog Devices technical support in one of the following ways: • Post your questions in the processors and DSP support community at EngineerZone ®...
  • Page 6: Supported Tools

    If you are a registered user, just log on. Your user name is your e-mail address. EngineerZone EngineerZone is a technical support forum from Analog Devices, Inc. It allows you direct access to ADI technical support engineers. You can search FAQs and technical information to get quick answers to your embedded process- ing and DSP design questions.
  • Page 7: Using The Board

    2 Using the Board This chapter provides information on the major components and peripherals on the board, along with instructions for installing and setting up the emulation software. Product Overview Below is an image of the ADSPSC835W-EV-SOM board. ® 2–1 ADSPSC835W-EV-SOM...
  • Page 8 Product Overview Figure 2-1: Board View The board features: • Analog Devices ADSP-SC835W processor • SHARC-FX Core • 400 ball BGA • 25 MHz oscillator • DDR3 Memory • 256Mx16 bit (4Gbit ) • ISSI IS43TR16256BL-107MBL • 1.39V • SPI Flash Quad (SPI2) Memory •...
  • Page 9: Package Contents

    Package Contents Your ADSPSC835W-EV-SOM package contains the following items. • ADSPSC835W-EV-SOM board Contact the vendor where you purchased your ADSPSC835W-EV-SOM evaluation board or contact Analog Devi- ces, Inc. if any item is missing. Default Configuration The Default Hardware Setup figure shows the default settings for jumpers and switches and the location of the jumpers, switches, connectors, and LEDs.
  • Page 10: Crosscore Embedded Studio (Cces) Setup

    ICE-1000 or ICE-2000 for debugging. When the ADSPSC835W-EV-SOM is connected to a carrier board the Debug Agent on the carrier board can be used. To use this Debug Agent, all postions on SW1 (on the carrier board) must be in the ON position. If an emula- tor, such as the ICE-1000 or ICE-2000, is used instead all postions on SW1 must be in the OFF position.
  • Page 11: Power-On-Self Test

    Power-On-Self Test ADSPSC835W-EV-SOM is connected to a carrier board the power is supplied via the carrier board. When in this mode the jumper on JP1 should be on Pins 2-3 to select power input from the carrier board. Power-On-Self Test The Power-On-Self-Test Program (POST) tests all the EZ-KIT carrier board peripherals and validates functionality as well as connectivity to the processor.
  • Page 12: Is43Tr16256Bl - 256Mx16 4Gb Ddr3 Sdram

    • TDQS (Termination Data Strobe) supported (x8 only) • OCD (Off-Chip Driver Impedance Adjustment) • Dynamic ODT (On-Die Termination) • Driver strength : RZQ/7, RZQ/6 (RZQ = 240 Ω) • Write Leveling • Up to 200 MHz in DLL off mode 2–6 ® ADSPSC835W-EV-SOM Manual...
  • Page 13: Lt8636 - 42V, 5A/7A Peak Synchronous Step-Down Silent Switcher With 2.5Μa Quiescent Current

    5MHz. For systems with higher power requirements, multi-phasing parallel converters is readily implemented. The LTC3310S uses a constant-frequency, peak current mode control architecture for fast transient response. A 500mV reference allows for low voltage outputs. 100% duty cycle operation delivers low drop out. ® 2–7 ADSPSC835W-EV-SOM Manual...
  • Page 14: Adp151 - Ultralow Noise, 200 Ma, Cmos Linear Regulator

    Short-circuit and thermal overload protection circuits prevent damage in adverse conditions. The ADP151 is availa- ble in tiny 5-lead TSOT, 6-lead LFCSP, and 4-ball, 0.4 mm pitch, halide-free WLCSP packages for the smallest footprint solution to meet a variety of portable power application requirements. 2–8 ® ADSPSC835W-EV-SOM Manual...
  • Page 15 ® ADSPSC835W-EV-SOM Manual...
