Scarab MERLIN Operating And Basic Maintenance Instructions page 4

WARNING - VOLTAGE SENSITIVE COMPONENTS.
DO NOT USE A BOOST STARTER / SUPER START, A BOOSTED START WILL BURN OUT THE VEHICLES ELECTRONIC CONTROL NODES, IF BATTERIES
ARE NOT CHARGED ALWAYS USE A FRESH SET.
TYPICAL WEIGHTS, DIMENSIONS AND CAPACITIES
GROSS VEHICLE WEIGHT (GVW)*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7.5 to 18 tonne
GROSS VEHICLE WEIGHT (GVW)* MAGNUM . . . . . . . . . . . . . . . . . . . . . . . . . . .15 to 18 tonne
OVERALL HEIGHT (hopper lowered)* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3000 to 3500mm
OVERALL LENGTH* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5640 to 7500mm
OVERALL WIDTH (brushes stowed)*. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2500mm
HOPPER GROSS VOLUME* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5.5³ to 8.2³ Gross
TANK CAPACITY*
Fuel Tank* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Typically 100 to 150 litres
Hydraulic Tank. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25 litres
Water Tank* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 900 litres to 4500 litres
NOISE LEVELS
In cab . . . . . . . . . . . . . . . . . . . . . . . . . . Between 70 - 84 dB(A) dependent on operating speed
External . . . . . . . . . . . .Maximum L of 114 dB(A) in accordance with directive 2000/14/EC
WA
VIBRATION
Description . . . All dynamic prime moving components are resiliently mounted to minimise
vibrations.In accordance with 2006/42/EC as amended.
Whole body . . . . . . . . . . . . . . . . . . . . . Equipment does not exceed 0.5 m/s² (RMS, weighted)
Hand & Arm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Equipment does not exceed 2.5 m/s² (VTV)
* Dependent upon model
In view of the fact that many variables such as chassis and machine specification
affect the weight and dimensions of the finished machine, it is not possible to quote
these precise details. If this type of information is required, please contact our
Technical Sales staff giving your sweeper's Serial Number.
Part No. SCAZ038022 2.4.1
Operating Instructions - Unidrive Truckmounted Road Sweeper
GENERAL INFORMATION
TOWING
SERIOUS DAMAGE TO THE TRANSMISSION WILL RESULT IF THE VEHICLE IS TOWED WHILE
THE GEARBOX IS ENGAGED.
If towing is necessary, it is imperative that the prop shaft is disengaged from the differential
or that the rear wheels are clear of the ground before making any attempt to tow the vehicle.
IDENTIFICATION PLATES
The SERIAL NUMBER PLATE is located on the rear face of the left hand suction nozzle spigot.
The Serial Number will comprise four numerical digits only (for example 5843).
For the location of the vehicle's VIN PLATE and CHASSIS NUMBER, refer to the chassis
manufacturers' documentation.
LIMITATIONS OF USE
The Scarab Merlin, Merlin XP and Magnum are classified as truck-mounted heavy-duty
suction road sweepers and, as such, are intended only for operation in the sweeping and
associated roles for which they have been expressly designed.
The sweeper bodywork is integrated to the truck/carrier vehicle, and is therefore not
demountable.
APPLICABILITY
This manual covers the operating requirements of the Scarab Merlin, Merlin XP and
Magnum Hydrostatic sweepers with the CANbus 3 system.
Warning
CB Radios and other electrical equipment used in the sweeper should be
properly suppressed (EMC) to prevent the possibility of interference in the
sweeper electronic system
E&OE
