Scarab M6 Operating Instructions

SCARAB M6 - Abbreviated Operating Instructions
AUXILIARY ENGINE
START/STOP + SWEEP MODE
MAIN PANEL
OPTIONS*
SIDE BRUSH
DOWN PRESSURE*
LEFT HAND
SUCTION NOZZLE
LEFT HAND
SIDE BRUSH
LEFT HAND
WORK LIGHT
REDUCE
ENGINE SPEED
LEFT HAND
WATER
OPTIONS*
WIDE SWEEP
WATER
NOT APPLICABLE
AUXILIARY PANEL
HIGH‐PRESSURE
WATER PUMP *
NOZZLE TILT
FAVOURITE SETTING
MULTI‐FUNCTION
SWITCH
MAJOR ON‐SCREEN INFORMATION
OPTIONS*
WIDE SWEEP
DOWN PRESSURE*
SUCTION FAN
WIDE SWEEP BRUSH
RIGHT HAND
SUCTION NOZZLE
H‐P WATER
RIGHT HAND
SIDE BRUSH
HOPPER NOT
RIGHT HAND
WORK LIGHT
INCREASE
REMOTE CONTROL
ENGINE SPEED
RIGHT HAND
WATER
OPTIONS*
*OPTIONS
SUCTION FAN
NOT APPLICABLE
MULTI‐FUNCTION LEVER
ON RIGHT HAND DRIVE VEHICLES
Move the switch to the right to swing the
side brush(es) OUT.
Move the switch to the left to swing the
side brush(es) IN.
Opposite for left hand drive.
NOZZLE‐TILT FUNCTION
Move the switch back to momentarily tilt
the suction nozzle or to close it from
LOCKED OPEN. Press and hold down the Safety Interlock and the
appropriate control switch.
For safety reasons only operate the Remote
OFF
Control controls from outside the vehicle,
from a vantage point that affords a good view
of the sweeper and its surroundings.
SIDE SIDE
ON
BRUSH BRUSH
Before closing the rear door, ensure adequate
NOZZLE clearance and seal cleanliness.
TILT
TO ENTER SWEEP MODE
VEHICLE ENGINE RUNNING. AIR TANKS FULL.
1.
Press the Start Switch on the main panel to start the auxiliary engine and enter sweep mode.
AND WARNING SYMBOLS
2.
Preselect the required sweeping combination. As each item is selected the corresponding
symbol on the LCD monitor will change as illustrated below. Start the suction fan.
3.
Engage a suitable gear ratio and release the clutch to commence sweeping.
WHEN REVERSING
ACTIVE FAULT SERVICE
ON PRESENT REMINDER
1.
When reverse gear is selected, all sweeping gear will automatically stop and retract.
2.
When reverse is deselected, all active sweeping equipment will redeploy.
LEAVING SWEEP MODE
1.
Move the multi‐function switch forward to the OFF position to stop and retract all active
H‐P PUMP WATER TANK
PUMP NO WATER LOW sweeping equipment.
2.
Switch off the suction fan.
REAR DOOR & HOPPER CONTROLS
The hopper safety prop must always be deployed when working beneath a raised hopper.
HYDRAULIC OIL HYDRAULIC OIL
Rear door safety prop must be deployed and when working beneath open rear door.
DOWN LOW TEMP
DISCHARGING THE PAYLOAD (TIPPING)
1.
Simultaneously press the safety interlock and door open switch, until the door is fully open.
2.
Simultaneously press the safety interlock and hopper raise switch, until the hopper is fully
raised.
Before lowering the hopper, ensure that the area below it is clear. Stow the hopper prop.
3.
Simultaneously press the safety interlock and hopper down switch, until the hopper is fully
RAISE HOPPER
down.
Before closing the rear door, ensure all personnel are clear of the immediate area and that
the door seal and seal‐mating face are clean. Stow the rear door prop.
LOWER HOPPER
4.
Simultaneously press the safety interlock and door close switch, until the door is fully closed.
Before stopping the auxiliary engine, allow it to idle for at least 2 minutes to allow the turbo‐
OPEN DOOR
charger to cool down.
WIDE SWEEP WATER ACTIVE
CLOSE DOOR
NOT APPLICABLE
SAFETY INTERLOCK
HOPPER RAISE/LOWER AND REAR
DOOR OPEN/CLOSE WARNING BUZZER
PRESS TO DISABLE
This document is designed as a quick reference guide, to allow the operator to drive the
vehicle in Sweep Mode and operate the basic controls. It does not constitute the full operating
instructions.
BRUSH ACTIVE
WATER ACTIVE
NOZZLE TILT INDICTOR
WORK LIGHT ON
PLEASE REFER TO REVERSE FOR HEALTH & SAFETY ADVICE
MAIN EQUIPMENT COLOUR CODES
EQUIPMENT NOT SELECTED
EQUIPMENT PRE‐SELECTED
EQUIPMENT OPERATING
WATER PRE‐SELECTED
EQUIPMENT + WATER PRE‐SELECTED
E&OE
