5. DDC Function

5.1 Plug & Play
This monitor abides by VESA DDC2B.
See page 5-29 for EDID data.
Monitor can output EDID data, although PC+5V from PC is inactive.

5.2 Remote Control

This monitor abides by VESA DDC/CI.

6. Other Function

6.1 Full Scan Capacity

In case the input video mode is not native resolution, the image area shall be expanded to native resolu-
tion smoothly with the function of scaling engine.
Standard resolution : 1680x1050
Expand method : Full expand mode with smoothing as follows
Down scaling : Down scaling at over 1680x1050 mode.
Picture Size (In Full-Screen mode)
Multi-pixel mode
Expansion
Expansion
Expansion
Expansion
Expansion
Expansion
Expansion
Expansion
Expansion
Expansion
Expansion
Expansion
Expansion
Expansion
Expansion
Expansion
Standard
Input display Expanded Rate
Resolution Horizontal
720×350 2.33
640×350 2.62
640×400 2.62
720×400 2.33
640×480 2.62
800×600 2.1
832×624 2.02
1024×768 1.64
1152×864 1.45
1152×870 1.45
1152×900 1.45
1280×768 1.31
1280×960 1.31
1360×768 1.23
1400×900 1.2
1400×1050 1.2
1680×1050 1.0
5-15
Expanded
Vertical Resolution
3 1680×1050
3 1680×1050
2.62 1680×1050
2.62 1680×1050
2.18 1680×1050
1.75 1680×1050
1.68 1680×1050
1.36 1680×1050
1.21 1680×1050
1.20 1680×1050
1.16 1680×1050
1.36 1680×1050
1.09 1680×1050
1.36 1680×1050
1.16 1680×1050
1.0 1680×1050
1.0 1680×1050
