Controls
OSM (On-Screen Manager) control buttons on the front of the monitor
function as follows:
To access OSM menu, press any of the control buttons (MENU/EXIT, Left, Right, Down, Up).
To change signal input, press the SELECT button.
To change DV MODE, press the RESET/DV MODE button.
NOTE: OSM must be closed in order to change signal input.
Button Menu
MENU/EXIT Open OSM main menu.
Exits the OSM controls.
Exits to the OSM main menu.
Up
4-Direction-Key
Left
Down
Left/Right Moves the highlighted area left/right to select control menus.
Moves the bar left/right to increase or decrease the adjustment.
Direct adjust of brightness if HOT KEY is set to ON.
Enters the OSM menu if HOT KEY is set to OFF.
Down/Up Moves the highlighted area down/up to select one of the controls.
Direct adjust of contrast if HOT KEY is set to ON.
Enters the OSM menu if HOT KEY is set to OFF.
SELECT/ Enter the OSM sub menu. Active the selected function.
1<->2RESET Change the Input source.
RESET/DV MODE Resets the highlighted control menu to the factory setting. Switches the DV Mode.
NOTE: When RESET is pressed in the main and sub-menu, a warning window will appear allowing you to cancel the
RESET function by pressing the MENU/EXIT button.
Brightness/Contrast Controls
BRIGHTNESS
Adjusts the overall image and background screen brightness.
CONTRAST
Adjusts the image brightness in relation to the background.
AUTO CONTRAST (Analog input only)
Adjusts the image displayed to optimal settings.
ADVANCED DV MODE
Activates the Advanced Dynamic Video Mode.
DV MODE
Dynamic Visual Mode allows you to select setting for Movie, Photo and etc.
Auto Adjust (Analog input only)
Automatically adjusts the Image Position, H. Size and Fine settings.
Right
