NEC MultiSync 20WGX2 Series Service Manual page 81

Item
Pixel frequency
Horizontal frequency
Line Time total
Horizontal active display
Horizontal sync pulse
Horizontal back porch
Horizontal front porch
Horizontal sync polarity
Vertical Frequency
Frame time total
Vertical active display
Vertical sync pulse
Vertical back porch
Vertical front porch
Vertical sync polarity
Item
Pixel frequency
Horizontal frequency
Line Time total
Horizontal active display
Horizontal sync pulse
Horizontal back porch
Horizontal front porch
Horizontal sync polarity
Vertical Frequency
Frame time total
Vertical active display
Vertical sync pulse
Vertical back porch
Vertical front porch
Vertical sync polarity
No.
Abbreviation
VESA 800×600 56Hz
fc
36.00MHz
fh
35.16kHz
Th
28.44us
Thd
22.22us
Thp
2.00us
Thb
3.56us
Thf
0.67us
POS (/NEG)
fv
56.25Hz
Tv
17.78ms
Tvd
17.07ms
Tvp
0.06ms
Tvb
0.63ms
Tvf
0.03ms
POS (/NEG)
No.
Abbreviation
VESA 800×600 72Hz
fc
50.000MHz
fh
48.08kHz
Th
20.80us
Thd
16.00us
Thp
2.40us
Thb
1.28us
Thf
1.12us
POS (/NEG)
fv
72.19Hz
Tv
13.85ms
Tvd
12.48ms
Tvp
0.13ms
Tvb
0.48ms
Tvf
0.77ms
POS (/NEG)
5-33
MODE
9
VESA 800×600 60Hz
40.00MHz
37.88kHz
1024CLK 26.40us
800CLK 20.00us
72CLK 3.20us
128CLK 2.20us
24CLK 1.00us
60.32Hz
625H 16.58ms
600H 15.84ms
2H 0.11ms
22H 0.61ms
1H 0.03ms
MODE
11
VESA 800×600 75Hz
49.500MHz
46.88kHz
1040CLK 21.33us
800CLK 16.16us
120CLK 1.62us
64CLK 3.23us
56CLK 0.32us
75.00Hz
666H 13.33ms
600H 12.80ms
6H 0.06ms
23H 0.45ms
37H 0.02ms
MODE
10
1056CLK
800CLK
128CLK
88CLK
40CLK
POS (/NEG)
628H
600H
4H
23H
1H
POS (/NEG)
MODE
12
1056CLK
800CLK
80CLK
160CLK
16CLK
POS (/NEG)
625H
600H
3H
21H
1H
POS (/NEG)
