NEC MultiSync 20WGX2 Series Service Manual page 87

Item
Pixel frequency
Horizontal frequency
Line Time total
Horizontal active display
Horizontal sync pulse
Horizontal back porch
Horizontal front porch
Horizontal sync polarity
Vertical Frequency
Frame time total
Vertical active display
Vertical sync pulse
Vertical back porch
Vertical front porch
Vertical sync polarity
Item
Pixel frequency
Horizontal frequency
Line Time total
Horizontal active display
Horizontal sync pulse
Horizontal back porch
Horizontal front porch
Horizontal sync polarity
Vertical Frequency
Frame time total
Vertical active display
Vertical sync pulse
Vertical back porch
Vertical front porch
Vertical sync polarity
Non-interlaced PAL
No.
GTF1024x768 50Hz
Abbreviation
fc 51.89MHz
fh 39.55kHz
Th 25.28us
Thd 19.73us
Thp 2.00us
Thb 2.78us
Thf 0.77us
NEG (/POS)
fv 50.000Hz
Tv 20.00ms
Tvd 19.42ms
Tvp 0.08ms
Tvb 0.48ms
Tvf 0.03ms
NEG (/POS)
Non-interlaced PAL
No.
Abbreviation GTF1280x960 50Hz
fc 82.99MHz
fh 49.40kHz
Th 20.24us
Thd 15.42us
Thp 1.64us
Thb 2.41us
Thf 0.77us
NEG (/POS)
fv 50.000Hz
Tv 20.00ms
Tvd 19.43ms
Tvp 0.06ms
Tvb 0.49ms
Tvf 0.02ms
NEG (/POS)
5-39
Non-interlaced PAL
33
GTF1280x720 50Hz
60.47MHz
37.05kHz
1312CLK 26.99us
1024CLK 21.17us
104CLK 2.12us
144CLK 2.91us
40CLK 0.79us
50.000Hz
791H 20.00ms
768H 19.43ms
3H 0.08ms
19H 0.46ms
1H 0.03ms
Non-interlaced PAL
35
GTF1280x1024 50Hz
89.379MHz
52.70kHz
1680CLK 18.975us
1280CLK 14.321us
136CLK 1.52us
200CLK 2.33us
64CLK 0.81us
50.000Hz
988H 20.00ms
960H 19.43ms
3H 0.06ms
24H 0.49ms
1H 0.02ms
34
1632CLK
1280CLK
128CLK
176CLK
48CLK
NEG (/POS)
742H
720H
3H
17H
1H
NEG (/POS)
36
1696CLK
1280CLK
136CLK
208CLK
72CLK
NEG (/POS)
1054H
1024H
3H
26H
1H
NEG (/POS)
