NEC MultiSync 20WGX2 Series Service Manual page 85

Item
Pixel frequency
Horizontal frequency
Line Time total
Horizontal active display
Horizontal sync pulse
Horizontal back porch
Horizontal front porch
Horizontal sync polarity
Vertical Frequency
Frame time total
Vertical active display
Vertical sync pulse
Vertical back porch
Vertical front porch
Vertical sync polarity
Item
Pixel frequency
Horizontal frequency
Line Time total
Horizontal active display
Horizontal sync pulse
Horizontal back porch
Horizontal front porch
Horizontal sync polarity
Vertical Frequency
Frame time total
Vertical active display
Vertical sync pulse
Vertical back porch
Vertical front porch
Vertical sync polarity
No.
Abbreviation
VESA 1152x864 70Hz
fc 94.50MHz
fh 63.851kHz
Th 15.661us
Thd 12.190us
Thp 1.016us
Thb 2.116us
Thf 0.339us
fv 70.012Hz
Tv 14.283ms
Tvd 13.531ms
Tvp 0.047ms
Tvb 0.689ms
Tvf 0.016ms
i810 DVD resolution
No.
Abbreviation i810 720x576 60Hz
fc 32.98MHz
fh 36.160kHz
Th 27.653us
Thd 21.831us
Thp 1.941us
Thb 3.184us
Thf 0.697us
fv 60.570Hz
Tv 16.510ms
Tvd 15.929ms
Tvp 0.055ms
Tvb 0.498ms
Tvf 0.028ms
5-37
MODE
25
1480CLK
1152CLK
96CLK
200CLK
32CLK
POS (/NEG)
912H
864H
3H
44H
1H
POS (/NEG)
27
912CLK
720CLK
64CLK
105CLK
23CLK
POS (/NEG)
597H
576H
2H
18H
1H
POS (/NEG)
MODE
26
VESA 1280x960 75Hz
129.60MHz
75.000kHz
13.333us 1728CLK
9.877us 1280CLK
0.988us 128CLK
1.975us 256CLK
0.494us 64CLK
POS (/NEG)
75.000Hz
13.333ms 1000H
12.800ms 960H
0.040ms 3H
0.480ms 36H
0.013ms 1H
POS (/NEG)
i810 DVD resolution
28
i810 720x576 75Hz
42.95MHz
45.500kHz
21.979us 944CLK
16.764us 720CLK
1.490us 64CLK
1.513us 65CLK
2.212us 95CLK
POS (/NEG)
75.581Hz
13.231ms 602H
12.660ms 576H
0.044ms 2H
0.506ms 23H
0.022ms 1H
POS (/NEG)
