1. General Description

Product Specifications
LCD
Input Signals
Preset Timings
USB Hub (only AN/BNBK)
Functions
Regulations
Environment
Condition
Power Supply
Weight
Dimension
VESA compatible arm mounting interface
Tilt / Swivel / Rotation / Height Adjustment
Accessories
*1)60% of a mass-product should meet
Item
Size
Active Display Area
Resolution
Pixel Pitch
Color Depth
Luminance
Viewing CR>10
Angle(Typ.)
CR>5
Contrast Ratio
ON+OFF
Response
Time GTG
Color gamut
Surface Treatment
Back Light
Horizontal frequency
Vertical frequency
Video Signal
Sync. Signal
Pixel Clock
Input connector
Front Control
Back side
OSM
Remote Control
Safety
EMC
VLF / ELF
Power Management
Ergonomics
Plug and Play
Others
Temperature
Humidity
Input Voltage
Typ
Power
consumption Power
saving
Input Connector
with Stand
without Stand
Net
Gross
AC Power code
Signal Cable
Others
Specification
Analog Input
LPL LM201WE2-SLA1
20.1" (51.1133cm)
433.44 (H) x 270.90 (V) mm
1680x1050 dots (WSXGA+)
0.258mm
16,77 M color (8-bits)
2
470cd/m (Typ.) *1)
Up 89 / Down 89 / Left 89 / Right 89 (Typ.)
-
700:1(Typ.)
1600:1 (Typ.) (Advanced DV mode "ON")
12ms
6ms by overdrive circuit integrated in panel
> 72%
Glare (AR<2.0%)
CCFL x 10pcs (Direct Light Type)
24.7kHz - 81.2kHz
49.0Hz - 76.0 Hz
Analog RGB
Separate Sync.(TTL)
Composite
Sync.on Green video
25.2MHz – 165MHz
Mini D-sub 15Pin
User preset : 23
USB Version 2.0 Self Powered Hub
1 upstream / 4 down stream
Menu/Exit, Direction (4 direction key), Select/1<->2,
Reset/DV mode, Power (DC)
Power (AC)
Brightness, Contrast, Auto contrast, Advanced DV mode, DV mode,
Auto adjust, H Position, V position, H size, Fine, Color control,
Sharpness, Expansion mode, Off timer, LED Brightness, Hot key,
Factory preset, Language, OSM Left/Right, OSM Down/Up, OSM
turn off, OSM Lock out, Resolution notifier, Monitor inf.
VESA DDC/CI
UL/ cUL , TuV GS, CE, CB Report, PSB
FCC Class B, Canadian DOC Class B, C-tick Class B, CE
MPR-II, MPRIII, TCO' 03
VESA DPMS ,EPA, Energy star Ver 4.0 Tier2, GEEA label
TUV/ERGONOMIE, TCO' 03
VESA DDC2B
US Mercury Regulation, Windows XP/2000 Logo
5-35 degree C
10-80% (without condensation)
AC100-240V, 50 / 60Hz
84 W max (1.0 A @ 100 - 120V, 0.52 A @ 220 - 240V)
<2.3W with USB hub model, <2W without USB hub (DPMS)
<1W (DC Power Off) Meet to Energy Star Ver 4.0 Tier 2
3P IEC Type
Approx. 6.3 kg
Approx. 4.6 kg
471.4 (W) x 391.5(H) x 203.0(D) mm
570.0(W) x 518.0(H) x 262.0(D) mm
100mmx100mm
Up & Down 30deg to -5deg / Yes +/- 170degree / NA / NA
2.0m
2.0m : minD-sub15pin - minD-sub15pin
2.0m: DVI-D - DVI-D
User's manual, USB cable, etc.
5-3
Digital Input
24.7kHz - 81.2kHz
Digital RGB
TMDS
DVI-D
