NEC MultiSync 20WGX2 Series Service Manual page 83

Item
Pixel frequency
Horizontal frequency
Line Time total
Horizontal active display
Horizontal sync pulse
Horizontal back porch
Horizontal front porch
Horizontal sync polarity
Vertical Frequency
Frame time total
Vertical active display
Vertical sync pulse
Vertical back porch
Vertical front porch
Vertical sync polarity
Item
Pixel frequency
Horizontal frequency
Line Time total
Horizontal active display
Horizontal sync pulse
Horizontal back porch
Horizontal front porch
Horizontal sync polarity
Vertical Frequency
Frame time total
Vertical active display
Vertical sync pulse
Vertical back porch
Vertical front porch
Vertical sync polarity
No.
Abbreviation
SUN 1152×900 66Hz
fc
94.50MHz
fh
61.85kHz
Th
16.17us
Thd
12.19us
Thp
1.35us
Thb
2.20us
Thf
0.42us
POS (/NEG)
fv
66.0Hz
Tv
15.15ms
Tvd
14.55ms
Tvp
0.07ms
Tvb
0.50ms
Tvf
0.03ms
POS (/NEG)
No.
Abbreviation
VESA 1280×1024 60Hz
fc
108.00MHz
fh
63.981kHz
Th
15.63us
Thd
11.85us
Thp
1.04us
Thb
2.30us
Thf
0.44us
POS (/NEG)
fv
60.02Hz
Tv
16.67ms
Tvd
16.00ms
Tvp
0.05ms
Tvb
0.59ms
Tvf
0.02ms
POS (/NEG)
5-35
MODE
17
VESA 1280×960 60Hz
108.00MHz
60.00kHz
1528CLK 16.67us
1152CLK 11.85us
128CLK
208CLK
40CLK
60.00Hz
937H 16.67ms
900H 16.0ms
4H 0.05ms
31H 0.60ms
2H 0.017ms
MODE
19
SUN 1280×1024 66Hz
117.00MHz
71.69kHz
1688CLK 13.95us
1280CLK 10.94us
112CLK
248CLK
48CLK
66.69Hz
1066H 15.00ms
1024H 14.4ms
3H
38H 0.46ms
1H 0.03ms
MODE
18
1800CLK
1280CLK
1.04us 112CLK
2.89us 312CLK
0.89us 96CLK
POS (/NEG)
1000H
960H
3H
36H
1H
POS (/NEG)
MODE
20
1632CLK
1280CLK
0.96us 112CLK
1.91us 224CLK
0.14us 16CLK
POS (/NEG)
1067H
1024H
0.11ms 8H
33H
2H
POS (/NEG)
