Command-Centre
2.1 HydroTap
G4 Chilled models
®
also refer to the tube kit assembly instructions) supplied with the tap.
Elite
Classic
Braided hose fitting
Install the mains water braided hoses to the
Command-Centre
before locating in place.
TM
POWER
CABLE
Clearance envelope
50mm
Note The braided hoses and connection tubes supplied with the tap head assembly and cold inlet CANNOT
be lengthened. Insulation provided must be fitted over the blue chilled tube, after trimming to length.
Page 12 of 16
Section 2
Refer to 803341UK Tap installation instructions (for Arc / Cube
Arc / Cube
USB
286mm
50mm
801525UK G4 Commercial chilled only installation instructions - June 2016 - V2.04
installation
TM
CHILLED
OUT
Note All silicon tubes must be cut to size. They must
have a constant fall back to the
Command-Centre
COLD isolation valve
MAINS
TM
Note Ambient mains water
braided hose length is 750mm.
Electrical power cable length is
3.0m nom.
Position the Command-Centre
according to the hose and cable
lengths supplied.
(not supplied)
IN
TM
