2.4
Installing Dail-rail mounting
The MVS100-323-Fl provides DIN-rail Mount for installing as below:
Step 1
Prepare the DIN-rail mount kit ready, including the screws and bracket.
Step 2
Install the bracket and fasten all screws tight, as illustrated below.
Hardware Installation
→
MVS100-323-FL User's manual
23
