Pos. Symbol Description
Grundfos Eye
Shows the operating status of individual
1 pumps.
For further information, see section
17. Grundfos
2 - Graphical color display.
3 Goes one step back.
Navigates between main menus, displays
and digits.
When you change the menu, the display
always shows the top display of the new
menu.
Navigates between submenus.
Changes value settings.
Note: If you have disabled the function to
configure settings with the Enable/Disable
Settings function, you can temporarily
enable it again by pressing these buttons
simultaneously for at least 5 seconds. See
section "Buttons on
Saves changed values, resets alarms and
4
expands the value field.
Enables radio communication with
Grundfos GO Remote and other products
of the same type.
When you try to establish radio
communication between the pump and
Grundfos GO Remote or another pump,
the green indicator light in Grundfos Eye
flashes. A note also appears in the pump
display stating that a wireless device wants
to connect to the pump. Press
pump control panel to allow radio
communication with Grundfos GO Remote
and other products of the same type.
Makes the pump ready for operation, and
starts and stops the pump.
Start:
If you press the button when the pump is
stopped, the pump only starts if no other
functions with higher priority have been
enabled. See section
5
settings.
Stop:
If you press the button when the pump is
running, the pump will always stop. When
you stop the pump via this button, the
icon appears in the bottom of the display.
6 Return to the Home menu.
16
Eye.
product".
on the
16. Priority of
10.2.1 Home display
1 2
Status Settings Assist
Setpoint Control mode
Const. pressure
5.00 bar
Operating mode Actual controlled value
Normal
4.90 bar
9 8 7 6
Fig. 28 Example of Home display
Pos. Symbol Description
Home
This menu shows up to four user-defined
parameters. You can select parameters
1 shown as shortcut icon
pressing
"Settings" display for the selected
parameter.
Status
This menu shows the status of the pump
2 -
and system as well as warnings and
alarms.
Settings
This menu gives access to all setting
parameters. You can make detailed
3 -
settings of the pump in this menu.
See section
for pumps.
Assist
This menu enables assisted pump setup,
4 - provides a short description of the control
modes and offers fault advice.
See section Assist.
Indicates that the pump has been stopped
5
via the
Indicates that the pump is functioning as
6
master pump in a multi-pump system.
Indicates that the pump is functioning as a
7
slave pump in a multi-pump system.
Indicates that the pump is operating in a
8 multi-pump system. See section
13.11 "Multi-pump
Indicates that the function to configure
settings has been disabled for safety
9
reasons. See section
product".
3 4
5
, and when
you go directly to the
13. Description of functions
button.
setup".
"Buttons on
