Technical Information
A.5.6 Configuration interface
INTERFACES
PROTOCOLS
SPEED
CONNECTOR
A.5.7 Power supply
INPUT VOLTAGE
INPUT CURRENT
FUSE
MAXIMUM POWER
ACC/IGNITION
CONNECTOR
A.5.8 Dimensions and weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
36
This can be configured in two modes:
Asynchronous Port:
V24 DCE. Does not permit Hardware flow control.
Local Console:
V.24 DCE only 8-N-1, without flow control.
Asynchronous Port:
AT, PPP, GPS-DATA.
Asynchronous Port:
300 to 115.200 bps.
Local Console:
9.600 bps (configurable up to 115.200).
DB9 female, on the front panel of the device.
Nominal: 12-24 V DC, Absolute minimum: 10.8 V DC.
Absolute maximum: 36 V DC.
2 A@12Vdc.
3.15 A 250 V AC Type: FSF.
With a WWAN module installed: 12 W.
With a WWAN+WIFI module installed: 15 W.
With two WWAN+WIFI modules installed: 19 W.
Input voltage: +12 - 24 V DC.
Current: 7 mA@12Vdc, 14mA@24Vdc.
Control Levels:
- ON: the same level as the INPUT VOLTAGE (+12 or +24 V DC).
- OFF: GND or not connected.
4 Pin polarized connector.
Ruggedized housing with multiple support positions.
216 x 210 x 50 mm.
2.0 kg.
